5 Operation
Maneuvering coupling with automatic lock
1
Fig. 119
Hitch a trailer as follows:
1. Press retaining spring 1 to release the pin.
2. Turn the pin 90° with lever 2.
3. Pull out the pins.
4. Slowly reverse the machine toward the trailer drawbar.
5. Insert the pin and turn it 90° with the lever.
5-102
2
Automatic trailer coupling
WARNING
Danger of crushing due to unintentional actuation of
the trailer coupling!
The trailer pin closes abruptly and can cause serious
injury.
► Keep all parts of the body away from the range of
action of the automatic trailer coupling.
► Alway keep the trailer coupling closed when it is not in
use.
NOTICE
If the machine is equipped with the rear 3-point mount
option, the upper linkage can collide with the trailer
coupling and be damaged when the 3-point mount is
lowered.
►
Removing the trailer coupling on page 5-103
3-point mount is used.
BA TH412 * 06/2017 * 4512_5-13_4_Opt_Anhaenger_en.fm
if the rear
