7.3
Fluids and lubricants
Fluids and lubricants (overview)
Position
Fuel tank
Engine oil with filter
TH412cc40
TH412cc35
Cooling system contents
TH412cc40
TH412cc35
Front axle
Rear axle
Transfer gearbox
Per wheel gear reduction
Complete hydraulic sys-
tem
Hydraulic oil reservoir
Grease lubrication points
When filling oil, the oil level must reach the marks on the dipsticks or control screws.
BA TH412 * 06/2017 * 4512_7-3_Schmierstoffe_en.fm
Maintenance
Capacity
Fluid
25.0 liters (6.60 gal.)
Diesel fuel
Engine oil SAE 15W40 ambient
6.7 liters (1.76 gal.)
temperature −20 to +40 °C
5.5 liters (1.45 gal.)
8.5 liters (2.24 gal.)
Water with commercially available
8.3 liters (2.19 gal.)
HD coolant/antifreeze
2.5 liters (0.66 gal.)
2.5 liters (0.66 gal.)
Gearbox oil SAE 90 GL 5
0.3 liters (0.08 gal.)
0.5 liters (0.13 gal.)
45.0 liters (11.88 gal.)
Hydraulic oil HLP
40.0 liters (10.57 gal.)
Multi-purpose grease
Maintenance 7
Specification
DIN 51601 commercially avail-
able, see engine manual
API CG-4/API CH-4 see
engine manual
HD coolant/antifreeze: ASTM
D 4985
API GL 5
ISO VG 46
Water-resistant
7-21
