Operating "High Flow" hydraulic connections
NOTICE
Technical damage due to overheating of hydraulic
system.
► Always put switch 49 in the zero position if "High Flow"
is not required.
The "High Flow" hydraulic connections are operated with
switch 49 in Rocker switch panel 4.
Switch on the "High Flow" hydraulic connection:
• Press switch 49 to position I.
• Move the control lever 6 toward L until it locks into
place.
➥ "High Flow" is switched on.
Switch off the "High Flow" hydraulic connection:
• Move the control lever 6 back into the middle position.
• Move the rocker switch 49 to position 0.
➥ "High Flow" is switched off.
