5 Operation
Working with a load hook
Correct
Wrong
Fig. 89
5-64
When working with the load hook, the safety instructions
for operating lifting gear are to be observed
see chapter 2 "2.5 Lifting gear applications" on
page
2-10.
Raise loads only with a retracted telescopic boom!
Use chains for raising and transporting loads with a load
hook. The load must be freely suspended on the load
hook. The chain must not rub against the cutting edge.
Refer to the bucket's type label for the load hook payloads
of a specific bucket.
1. Hitch the chain onto the load hook.
2. Raise the loader unit to the required height and tilt out
the bucket.
3. With the bucket tilted out, travel over the load to be
raised.
4. Safely hitch the chain onto the load.
➥ The load can be raised and transported.
BA TH412 * 06/2017 * 4512_5-11_Arbeitsbetrieb_en.fm
–
