Side window
1
Fig. 21
BA TH412 * 06/2017 * 4512_4-1_Steuerstand_en.fm
CAUTION
Crushing hazard due to unlocked side window!
The side window can cause crushing when closing.
► Always lock the side window.
► Use the handholds for closing.
The side window can be locked in the open position.
Open and lock the side window with the lever 1.
•
Press the side window against the locking mechanism.
➥ The side window is safely locked.
•
Operate lever 1.
- The locking mechanism of side window is released.
➥ The side window can be closed.
Do not drive with the door open. The door is then open at
an angle of 90° and can be damaged.
Putting into operation 4
4-3
