Air suspension seat (option)
NOTICE
Damage to compressor when operating the weight
adjustment too long.
► Do not operate the weight adjustment more than 1
minute.
1. Horizontal adjustment
Horizontal adjustment is performed by operating the
locking lever upward.
Once the adjustment is made the locking lever must
engage in the required position.
Moving the operator seat to another position must no
longer be possible once it is locked.
Do not raise the locking lever with your leg or calf.
BA TH412 * 06/2017 * 4512_4-1_Steuerstand_en.fm
2. Weight adjustment
Sit down on the operator seat to adjust it to the specific
weight by pulling or pressing the weight adjustment lever.
The operator seat is adjusted to the correct weight if the
arrow is in the clear middle range of the window.
Within this visible range, the individual height can be
adjusted up to the minimum suspension travel.
The minimum or maximum weight adjustment is indicated
with the audible upper and lower limits.
Putting into operation 4
4-9
