Wacker Neuson Telehandler TH412 Operator's Manual page 353

Table of Contents

Advertisement

Item Designation
M1*
Max. tilt-out height with extended boom (bucket)
M2*
Max. tilt-out height with retracted boom (bucket)
N
Max. reach with M1
N1
Max. reach with extended boom (pallet forks)
N2
Max. reach with retracted boom (pallet forks)
O*
Scraping depth
P*
Overall width
Q*
Track
S*
Ground clearance
T
Max. radius (bucket)
T1
Max. radius (pallet forks)
U*
Radius at outer edge
V
Inner radius
X
Roll back angle at max. lift height
Y
Max. tilt-out angle
Z
Roll back angle at ground
Dimensions with tires 10.0/75-15.3 AS
All height dimensions refer to the static radius of the wheels.
*Dimensions differ if other tires or reversed wheel rims are used
BA TH412 * 06/2017 * 4512_9_Tech_Daten_en.fm
Technical data 9
mm
(in)
3611
142.17
2397
94.37
542
21.34
2279
89.72
920
36.22
94
3.70
1560
61.42
1296
51.02
286
11.26
3517
138.46
3409
134.21
2722
107.17
951
37.44
°
52
°
31
°
44
9-21
