Wacker Neuson Telehandler TH412 Operator's Manual page 351

Table of Contents

Advertisement

Item Designation
Overall length with standard bucket
A
Overall length with pallet forks
B
Length incl. quickhitch
C
Center of axle to attachment pivot
D
Wheelbase
E
Rear overhang
F*
Height above cabin/protective roof for operator
H*
Seat height
Total work height (bucket)
J*
Total work height (pallet forks)
K*
Max. height of attachment pivot
Load-over height with extended boom (bucket)
L1*
Pallet height with extended boom (pallet forks)
Load-over height with retracted boom (bucket)
L2*
Pallet height with retracted boom (pallet forks)
Dimensions with tires 10.0/75-15.3 AS
All height dimensions refer to the static radius of the wheels.
*Dimensions differ if other tires or reversed wheel rims are used
BA TH412 * 06/2017 * 4512_9_Tech_Daten_en.fm
Technical data 9
mm
(in)
3911
153.98
4038
158.98
2941
115.79
450
17.72
1920
75.59
391
15.39
1941
76.42
953
37.52
5218
205.43
4990
196.46
4531
178.39
4151
163.43
4386
172.68
2937
115.63
3072
120.95
9-19
