Operating the rear 3-point mount
50
1
0
2
Fig. 113
BA TH412 * 06/2017 * 4512_5-13_3_Opt_Heck_en.fm
The rear 3-point mount is operated with switch 50.
Position I automatically lowers the rear 3-point mount to
the lowest position. Position II raises the 3-point mount as
long as switch 50 is pressed.
•
Move the rocker switch 50 to position I.
- The switch remains in position I.
➥ The loaded rear 3-point mount is lowered.
•
Move the rocker switch 50 to position II.
➥ The rear 3-point mount is raised as long as the
switch is pressed.
Operation 5
5-95
