Item Lubrication point
Pivot point of quickhitch
1
2
Bearing for reversing lever
Rear tilt cylinder
3
Front lift cylinder
4
5
Rear compensating cylinder
Loader unit bearing
6
Lift cylinder (remote lubrication)
7
Rear center axis pin
8
(remote lubrication)
Lubricate all lubrication points every 20 operating hours with water resistant multi-purpose grease! Lubricate all other
moving parts such as the parking-brake lever, pedals, Bowden cables, etc. with an oil can!
BA TH412 * 06/2017 * 4512_7-2_Schmierplan_en.fm
Num-
Item Lubrication point
ber of
zerks
Rear kingpin
9
[2]
Front kingpin
10
[1]
Traction bar
11
[1]
Front tilt cylinder
12
[1]
Front compensating cylinder
13
[1]
(remote lubrication)
[1]
Angle sensor for Vertical Lift System
W
(VLS) see page
[1]
[1]
Maintenance 7
7-20
Num-
ber of
zerks
[4]
[4]
[2]
[1]
[1]
7-19
