5 Operation
Selecting the travel direction
I
0
II
Fig. 46
5-8
26
27
32
Forward-reverse control 32 operates the travel direction
of the machine. After starting the engine, the travel
direction is in neutral, self-contained of the position of the
forward-reverse control. Re-enabling the travel direction is
then necessary.
Select a travel direction:
• Forward-reverse control 32 in the middle position.
➥ Indicator lights 26 and 27 do not illuminate.
➥ No travel direction selected (zero position).
• Put the forward-reverse control 32 to position I.
➥ Indicator light 26 illuminates.
➥ Machine moves forward.
• Put the forward-reverse control 32 to position II.
➥ Indicator light 27 illuminates.
➥ Machine moves backward. A warning tone sounds
(option).
