5 Operation
Hydraulic lock for attachments (option)
R
6
L
0
1
Fig. 74
5-42
a
b
40
Operating the hydraulic lock for attachments
The hydraulic lock for attachments is operated with the
additional control lever 6.
1. Move the additional control lever 6 toward R.
➥ The quickhitch is locked.
2. Move the lock a in the rocker switch 40 (in Rocker
switch panel 1) towards b and hold down the rocker
switch 40.
3. Move additional control lever 6 toward L.
➥ The quickhitch is unlocked.
