7. Programmers' Reference 7. Programmers' Reference
7.3.9. Query the Application Mode
The application mode of the device can be Extender or Matrix. See the details about the two modes in the
Application Modes section.
Command and Response #applicationmode #extendermode #matrixmode
ç GET•/SYS/MB.ApplicationMode
pr•/SYS/MB.ApplicationMode=<application_mode>
æ
Parameters
Identifier Parameter description
The application mode of
<application_mode>
the endpoint device.
Example
ç GET /SYS/MB.ApplicationMode
æ pr /SYS/MB.ApplicationMode=Extender
7.3.10. Application Mode Selection

INFO: See the details about the two modes in the

INFO: The Auto mode is the recommended application mode setting.
Command and Response
SET•/SYS/MB.ApplicationModeSelection=<application_mode>
ç
pw•/SYS/MB.ApplicationModeSelection=<application_mode>
æ
Parameters
Identifier Parameter description
The application mode of
<application_mode>
the endpoint device.
Example
ç SET /SYS/MB.ApplicationModeSelection=Auto
æ pw /SYS/MB.ApplicationModeSelection=Auto
UBEX series – Extender Application Mode – User's Manual UBEX series – Extender Application Mode – User's Manual
Value Explanation
The endpoint device is in Extender
Extender
mode.
The endpoint device is in Matrix
Matrix
mode.
Application Modes section.
Value Explanation
The endpoint device detects the
application mode automatically
Auto
based on the connected remote
device.
The endpoint device is forced to be in
Extender
Extender mode.
The endpoint device is forced to be in
Matrix
Matrix mode.
Applied F-series endpoint firmware package: v1.4.1 | Applied R-series endpoint firmware package: v1.4.1 | LDC software: v1.34.0b2
7.3.11. Setting the Rotary Direction of the Jog Dial Knob
Command and Response #rotary #jogdial
SET•/MANAGEMENT/UI.RotaryDirection=<parameter>
ç
pw•/MANAGEMENT/UI.RotaryDirection=<parameter>
æ
Parameters
Identifier Parameter description
Rotary direction of the jog
<parameter>
dial control knob
Example
ç SET /MANAGEMENT/UI.RotaryDirection=1
æ pw /MANAGEMENT/UI.RotaryDirection=1
7.3.12. Setting the Brightness of the LCD Screen
Command and Response
SET•/MANAGEMENT/UI.DisplayBrightness=<parameter>
ç
pw•/MANAGEMENT/UI.DisplayBrightness=<parameter>
æ
Parameters
The <parameter> of display brightness can be set between 0 and 10 values.
Example
ç SET /MANAGEMENT/UI.DisplayBrightness=5
æ pw /MANAGEMENT/UI.DisplayBrightness=5
78 78
Value Explanation
The rotary direction of down is
0
clockwise (CW).
The rotary direction of down is
1
counter clockwise (CCW).
