SimonsVoss
Manual
SmartRelais 3 Advanced
12.4.3 SmartOutput module
12.5 Drilling templates
IMPORTANT
The drilling template scale is 1:1. You can print and the drilling templates in
A4 format.
Ensure that the print settings are not set to reduce or enlarge. Use the lines
under the drawings to check scale is correct.
12 | Technical specifications
132 / 135
