Simons Voss Technologies SmartRelais 3 Advanced Manual page 75

SimonsVoss
Manual
SmartRelais 3 Advanced
-
+
1(1)
<
1(2)
2(1)
<
2(2)
+1
-
B1
A1
+2
-
B2
Controller
A2
+3
-
B3
A3
O4
O3
O2
O1
O+
I3
I2
I1
-
I+
L
N
Power
supply unit
+
-
L
N
Power
supply unit
+
-
Trailing cable
Controller-fed reader with SmartOutput modules
The reader is connected as described before (see Power supply
through the controller [} 56]). The SmartOutput modules are also
powered via a power supply unit outside the cab. The SmartOutput
modules' earth system must be connected to the controller's earth
system.
6 | Setting up
+
Lift
electronics
-
-
+
-
Reader
B
A
75 / 135
