SimonsVoss
Manual
SmartRelais 3 Advanced
Line
1
2
3
4
5
SmartOutput module
in cab
Lift
electronics
Reader in
the unprotected area
Voltage converter
The earth cables in the power supplies are separated from the
common earth cable in this case.
See Common earth with SREL3 components [} 70] and Connecting
one or more readers [} 55] on wiring.
Use
Earth connection between controller, reader
and SmartOutput modules
Controller – reader: Data line A
Controller – reader: Data line B
Controller – SmartOutput module: Data line A
Controller – SmartOutput module: Data line B
Trailing cable
6 | Setting up
Ethernet connection to LSM
Optional PoE instead of PSU
Controller in the
protected area
44 / 135
Power
supply for
lift cab
External PSU
