SimonsVoss
Manual
SmartRelais 3 Advanced
Screw terminals
Ambient conditions
Temperature
range
Humidity Max. 90%, non-condensing
Interfaces
Acts as an interface to the SREL3 ADV system control-
ler.
RS485
Signal
1 RGB
LED
8 green
Relay
Quantity 8x, programmable separately from one another
Switching modes Monoflop
Programmable between 1 s and 25 s (except 0 s, as on
Switching interval
controller).
Contact type 1x NO
Contact material AgNi+Au
Service life (elec-
12 V
trics)
Service life
Typically 100 × 10
(mechanical)
Bounce time Typically 1 ms, max. 3 ms
15 G for 11 ms, 6 shocks as per IEC 68-2-27; not tested
Vibrations
for permanent operation under vibration
AUX relay switch-
Max. 24 V
ing voltage
AUX relay switch-
ing current
Switching voltage
Max. 24 V
in outputs
Switching current
Max. 200 mA
in outputs
12 | Technical specifications
– V : 12 V (11 V
IN DC DC
– Standby current: < 120 mA
– Max. current: < 150 mA
– Reverse voltage protection: yes
– 0 °C to +60 °C (operation)
– 0 °C to +70 °C (in storage > 1 week)
– Number of ports: 1
– Length: ≤ 150 m, max. distance 300 m (depending
on firmware and cabling)
/ 10 mA: typ. 5 × 10
DC
6
switching cycles
– Max. 1 A permanent current
– Max. 2 A switching current
–15 V )
DC
7
switching cycles
