6.4.5.5 Wiring in lift
Lift cabs are connected to the external system via trailing cables. The
number of available lines is limited by the trailing cable type. You can save
on free lines if you decide on a configuration with few lines.
GND
CLS
Third-party
system
CLK
DATA
