SmartRelais 3 Advanced
12.2.2 Reader
Used to connect external units. A potential-free contact
External contact can be connected between the inputs (I1, I2 or I3) and
the I+ connection.
Digital outputs
Quantity 4
Type Open drain
Switching voltage 30 V (ohmic load)
Switching current Max. 200 mA (ohmic load)
The O+ connection is available for the power supply. An
external pull-up resistor (about 1–10 kΩ) can be con-
Power supply
nected between the digital outputs (O1, O2, O3 or O4)
and O+.
Serial ZK interface
Supported proto-
cols
Electrical specific-
See digital outputs.
ations
Housing
Material ABS plastic, UV-stable
Colour 9/118645, same as RAL 9016 (traffic white)
IP20
Standard protec-
IP65 for WP variant
tion rating
Anti-vandalism housing available
Wiring to device Flush mount
Power supply
Screw terminals
Controller fed Supplied from looped-through controller supply current
Ambient conditions
Temperature
range
12 | Technical specifications
– Wiegand, 33 bit
– Wiegand, 26 bit
– Primion
– Siemens Cerpass
– Kaba Benzing
– Gantner Legic
– Isgus
– V : 9 V –32 V
IN DC DC
– Input current: max. 200 mA
– Reverse voltage protection: yes
– -25 °C to +60 °C (operation)
– 0 °C to +30 °C (in storage > 1 week)
124 / 135
