SmartRelais 3 Advanced

12.2.4 Recommended cable types

ATTENTION
ATTENTION
OUT switching
Max. 1 A
current
OUTPUT switch-
Max. 24 V
ing voltage
OUTPUT switch-
Max. 1 VA
ing power
OUT switching
behaviour for low U
voltage
Lines with data Cat 5 or installation cable for telecommunications sys-
transmission tems (e.g. F-YAY 2x2x0.6)
Lines with data
Cat 5 or installation cable for telecommunications sys-
transmission and
tems (e.g. F-YAY 2x2x0.6)
power supply
Lines for power
Any line (e.g. F-YAY 2x2x0.6)
supply only
Take voltage drop into account
The resistance in copper produces a voltage drop, the size of which de-
pends on the cable gauge, current flow and cable length. The power supply
lines must be adequately dimensioned.
1. Ensure that the cable gauge in lines is adequate for power supply. Use
another suitable cable where necessary.
2. If required, merge wire pairs to increase the cable gauge.
3. Use a power source located closer to the SmartOutput module if
needed.
4. If possible, increase the supply voltage (observe technical
specifications).
Malfunctions due to interference
Sources of interference may impair functional reliability.
1. Observe the installation instructions (see Installation [} 78]).
2. Use shielded cables.
12 | Technical specifications
< 10.5 ± 0.5 V corresponds to off
V
