SimonsVoss
Manual
SmartRelais 3 Advanced
Supplies electricity where required
Reads access lists
Updates time budgets
Writes authorisation changes
Emits signals (opt., aud.)
Reader 1
(obligatory)
Reader 2
(optional)
Reader 3
(optional)

6.4.4 Solutions for scenarios

IMPORTANT
DANGER
The controller can also respond to a digital entry and, consequently, a
connected button or similar as an alternative to successful
identification.
Forwards identification
media
As Reader 1 Controller
Transmits com-
As Reader 1
mands to actuate
SmartOutput module
(optional)
Parallel
circuit
SmartOutput module
(optional)
The SREL3 ADV system is the time-tested solution for a large number of
use cases. This section presents a few of them and shows how the SREL3
ADV system is used. The wiring is basically always as described in terms of
electrics (see wiring [} 55]). However, line lengths, cable types and wiring
installation options vary, depending on the use case.
Protected areas are areas which can only be accessed with an authorised
identification media or are secured against unauthorised access in some
other way.
Risk of injury due to incorrect programming
The SREL3 ADV system is not suitable to replace existing security installa-
tions.
1. Ensure that the SREL3 ADV system is used as an additional securing
measure only.
2. Do not replace existing security installations with the SREL3 ADV
system.
6 | Setting up
Internal relay
Digital outputs
Digital inputs
Connection to external
devices, e.g. electric strikes
Connection to external
devices, e.g. electric strikes
36 / 135
Connection to external
devices, e.g. electric strikes
Transmits commands to external
devices. Available protocols
see specifications
Push-to-open on 3
Connection to external
devices, e.g. buttons
