Simons Voss Technologies SmartRelais 3 Advanced Manual page 17

SimonsVoss
Manual
SmartRelais 3 Advanced
Circuit
No. Explanation
board
Controller connection: Data Line A; connected to con-
5 A
tact for Reader 3.
Controller connection: Earth; connected to contact for
6 C
Reader 3.
Relay 4: Potential-free contact (NC treated as NO in
7 4a
software); activated depending on authorisations.
Relay 4: Potential-free contact (NC treated as NO in
8 4b
software); activated depending on authorisations.
Relay 3: Potential-free contact (NC treated as NO in
9 3a
software); activated depending on authorisations.
Relay 3: Potential-free contact (NC treated as NO in
10 3b
software); activated depending on authorisations.
Relay 2: Potential-free contact (NC treated as NO in
11 2a
software); activated depending on authorisations.
Relay 2: Potential-free contact (NC treated as NO in
12 2b
software); activated depending on authorisations.
Relay 1: Potential-free contact (NC treated as NO in
13 1a
software); activated depending on authorisations.
Relay 1: Potential-free contact (NC treated as NO in
14 1b
software); activated depending on authorisations.
Relay 5: Potential-free contact (NC treated as NO in
15 5b
software); activated depending on authorisations.
Relay 5: Potential-free contact (NC treated as NO in
16 5a
software); activated depending on authorisations.
Relay 6: Potential-free contact (NC treated as NO in
17 6b
software); activated depending on authorisations.
Relay 6: Potential-free contact (NC treated as NO in
18 6a
software); activated depending on authorisations.
Relay 7: Potential-free contact (NC treated as NO in
19 7b
software); activated depending on authorisations.
Relay 7: Potential-free contact (NC treated as NO in
20 7a
software); activated depending on authorisations.
Relay 8: Potential-free contact (NC treated as NO in
21 8b
software); activated depending on authorisations.
Relay 8: Potential-free contact (NC treated as NO in
22 8a
software); activated depending on authorisations.
AUX relay: Potential-free contact (NO). Contact is con-
nected with K1 (number 26) if coil is connected to
power.
23 K2
Equipped with a detachable bridge to + (number 24) ex
works.
5 | Connections 17 / 135
