Use
Earth connection between SmartOutput mod-
ule and power supply unit
Positive terminal for power supply between
SmartOutput module and power supply unit
Earth connection between controller and
reader
Positive terminal for power supply between
controller and reader
Controller – SmartOutput module: Data line A
Controller – SmartOutput module: Data line B
Controller – SmartOutput module: Data line
earth connection
Controller – reader Data line A
Controller – reader Data line B
