Simons Voss Technologies SmartRelais 3 Advanced Manual page 66

SimonsVoss
Manual
SmartRelais 3 Advanced
6.4.5.4 Using the serial interface
Wiegand 26-bit and 33-
bit
Module Address
Module 3 2
Module 4 3
Module 5 4
Module 6 5
Module 7 6
Module 8 7
Module 9 8
Module 10 9
Module 11 A
Module 12 B
Module 13 C
Module 14 D
Module 15 E
Module 16 F
1. Press the sides of the transparent inlay together.
2. Remove the transparent inlay.
3. Use a screwdriver to configure the address as per the table.
4. Insert the transparent inlay again.
The digital outputs used for the serial interface are open drain connections.
This means that a pull-up resistance in the data lines and 3–24 V
required for operation as a serial interface. The O+ connection can be used
for this purpose. A value of 1 kΩ is recommended. The earth system in the
controller and the earth system in the third-party system must also be
connected for data transmission.
You can obtain detailed information and the specifications from Support
(see Help and contact). The required pull-up resistances may already be
integrated in your third-party system. In doubt, please ask the manufacturer
of your third-party system.
The controller can communicate with systems which use one of the
Wiegand protocols. Once an authorised identification medium is
detected, the data are forwarded to the third-party system via the
serial interface. The controller must be wired as follows to make this
possible.
6 | Setting up 66 / 135
are
DC
