SimonsVoss
Manual
SmartRelais 3 Advanced
Pin connector
Power over Ether-
net (PoE)
Outputs 3 outputs to supply external reader (V
Battery
Type 1x CR1220 lithium cell (3 V, 40 mAh)
Replaceable Yes
Battery life:
You can consult the battery level in LSM. Battery is not
used if controller is connected to a power supply.
Real time clock (RTC)
Accuracy Max. ± 20 ppm (≈ 10 minutes per year)
Ambient conditions
Temperature
range
Humidity Max. 90%, non-condensing
Interfaces
TCP/IP
USB
12 | Technical specifications
– V : 9 V –32 V
IN DC DC
– Input current: max. 200 mA
– Size: ≥ 2.0 mm inside Ø (recommended: 2.1 mm or
2.5 mm) and ≤ 5.5 mm outside Ø (recommended:
5.5 mm)
– IEEE 802.3af.-compliant
– Fully insulated
– V : 36 V to 57 V
IN DC
– POUT: max. 10 W
– Signalled by red LED
– > 10 years (inactive)
– > 2 years (active)
– -25 °C to +60 °C (operation)
– 0 °C to +30 °C (in storage > 1 week)
– Features: HP Auto_MDIX, DHCP client, IPv4
– 10BaseT/100BaseT standard
– TCP server: one each at Port 9760 and 9770
– IP address freely programmable, pre-set:
169.254.1.1
– Connection: RJ45
– High-speed USB
– Vendor ID: 0x2AC8, product ID: 0x101
– HID class device
– Connection: Mini B
DC
= V
OUT
122 / 135
– 1 V )
IN DC
