3.3 SmartOutput module

IMPORTANT

3.4 Versions

SmartOutput modules are ideal complements to controllers if more than
one relay output is required. Every SmartOutput module is equipped with
eight relays, which each feature a change-over contact. SmartOutput
modules can be connected in parallel to one another and fitted on a DIN rail
(35 mm x 7.5 mm).
A multi-coloured LED signals the different operating modes.
Follow the switch-on sequence
After a power-on reset (power outage followed by restoration of power sup-
ply), the controller automatically searches for connected system compon-
ents one time on restarting. System components which are not supplied
power until the controller restarts are thus unable to respond to the control-
ler's query and are not recognised.
The controller must therefore be supplied power with the other system com-
ponents at the same time or must be the last system component to receive
power.
Several improvements have been made for the newly launched SREL 3
ADV compared to its predecessor:
Comparison between SmartRelay 2 and SmartRelay 3
Duration of data trans-
mission to the gateway
3 | System description
SmartRelay 2
– Depending on the
data volume (push
principle)
10 / 135
SmartRelay 3 Advanced
– Immediate (pull
principle)
