SimonsVoss
Manual
SmartRelais 3 Advanced

12 Technical specifications

12.1 Order numbers

Controller

Reader

SmartOutput module

Accessories

12.2 Properties

12.2.1 Controller
SREL3.CTR.ADV.G2
SREL3.CTR.ADV.ZK.G2
SREL3.EXT.G2.W
SREL3.EXT.G2.W.WP
MOD.SOM8
POWER.SUPPLY.2
SREL2.COVER1
Housing
Material ABS plastic, UV-stable
Colour 9/118645, same as RAL 9016 (traffic white)
Standard protec-
IP20
tion rating
Wiring to device
Power supply
(only one power supply must be connected)
Screw terminals
12 | Technical specifications
– Flush mount
– Surface mounting
– V : 9 V –32 V
IN DC DC
– Input current: max. 200 mA
– Reverse voltage protection: yes
Controller for the SREL3 ADV
system (standard version)
Controller for the SREL3 ADV
system (version with time zone
management and event logging)
Reader for the SREL3 ADV sys-
tem (standard version)
Reader for the SREL3 ADV sys-
tem (version with splash water
protection)
SmartOutput module (standard
version)
Power supply unit (12 V
500 mA)
Anti-vandalism housing
121 / 135
,
DC
