SimonsVoss
Manual
SmartRelais 3 Advanced
8.2.1.2 Reading the access list over network
4. Select the "USB link to the TCP nodes" item.
5. Click on the Read button.
ð "G2 SmartRelay 3" window opens.
6. Click on the Read button.
7. Click on the Audit Trail button.
ð Access list is displayed.
Proceed as follows if you wish to read the access list using a network
connection:
ü Components wired correctly (see wiring [} 55]).
ü Components connected to power.
ü Controller has already been programmed.
ü Controller connected to computer via network.
1. Mark the entry on the SmartRelay 3 controller in the matrix.
2. Use | Programming | to select the Read highlighted locking device/set
time item.
8 | SREL3 ADV in LSM 81 / 135
