8.11.1 Extended configuration without SmartOutput module

Unlocking in the authorised time period (close relay contacts)
Unlocking automatically
always
Controller: Closes re-
lay contacts (un-
locked) as soon as
authorisation starts in
the time zone plan.
Behaves in the same
way as a flip-flop for
the remaining author-
ised time period.
Locking in the non-authorised time period (open relay contacts)
Locking automatically
always
Controller: Opens re-
lay contacts (locked)
as soon as authorisa-
tion ends in the time
zone plan. Identifica-
tion media close relay
contacts (unlock) dur-
ing non-authorised
time period for pre-set
pulse duration.
only if locked
Controller: Closes re-
lay contacts (un-
locked) as soon as
authorisation starts in
the time zone plan. No
influence by identifica-
tion media for the rest
of the authorised time
period.
only if locked
Controller: Opens re-
lay contacts (locked)
as soon as authorisa-
tion ends in the time
zone plan. Identifica-
tion media close relay
contacts (unlock) dur-
ing non-authorised
time period for pre-set
pulse duration.
8 | SREL3 ADV in LSM
Unlocking manually
always
Controller: Closes re-
lay contacts (un-
locked) as soon as
identification medium
is activated after au-
thorisation starts in
the time zone plan.
Behaves in the same
way as a flip-flop for
the remaining author-
ised time period.
Locking manually
always
Controller: Opens re-
lay contacts (locked)
as soon as identifica-
tion medium is activ-
ated. Identification
media close relay con-
tacts (unlock) during
non-authorised time
period for pre-set
pulse duration.
93 / 135
only if locked
Controller: Closes re-
lay contacts (un-
locked) as soon as
identification medium
is activated after au-
thorisation starts in
the time zone plan. No
influence by identifica-
tion media for the rest
of the authorised time
period.
only if locked
Not possible
