1 Intended use

In its third generation, the SimonsVoss SmartRelay system (SREL 3 ADV)
is a system consisting of several networked components which provide
intelligent control of locking devices and third-party systems. The system
consists of a controller, at least one external reader and an optional
SmartOutput module.
The controller is the main component. A service communicates with the
LSM database and provides the controller with the latest information from
the database when it is used as a gateway. No manual updates or time-
consuming reprogramming are required.
The controller can use information retrieved from the LSM database and
identification data transmitted by the reader to verify identification data with
the database. Different actions are possible, depending on the settings
programmed in the controller, including:
– Assigning authorisations
– Withdrawing authorisations
– Loading time budgets
– Updating identification media configurations
– Switching relay outputs
– Reading lists
Identification media are read by up to three external readers, which may be
physically separate from one another and the controller. In the third-
generation SmartRelay system, the reader can read active and passive
identification media and transmit the information to the controller for
evaluation.
The controller features a built-in relay output which can be freely
programmed. The system can be extended with SmartOutput modules in a
daisy chain featuring up to 116 relay outputs, which are also freely
programmable.
