SimonsVoss
Manual
SmartRelais 3 Advanced
SmartOutput module
in cab
Lift
electronics
6.4.4.4 Safe deposit boxes
Reader in
the unprotected area
Trailing cable
See Controller-fed reader with SmartOutput modules [} 75] and
Connecting one or more readers [} 55] on wiring.
Also see
2 Power supply from cab [} 42]
Safe deposit box systems are used by a variety of users. Only authorised
persons should be able to open their designated deposit boxes. Deposit
box systems are not always installed in areas protected from the weather.
Suppliers, deliverers and a selected group of people should be able to
access all deposit boxes. Some people may need to be able to open
several deposit boxes.
6 | Setting up
Ethernet connection to LSM
Optional PoE instead of PSU
Controller in the
protected area
49 / 135
External power supply
unit for SOM
Power
supply for
lift cab
External PSU
