SimonsVoss
Manual
SmartRelais 3 Advanced
IMPORTANT
IMPORTANT
Initial programming via USB
The controller can be addressed via TCP/IP. No IP is featured in storage
mode. That is why initial programming, during which an IP address is is-
sued, must be carried out with a USB connection.
ü Components connected to power.
ü Controller connected to computer with USB cable.
ü Reader connected to the controller (see wiring [} 55]).
ü LSM installed and launched as administrator.
ü System requirements met.
1. Create a new G2 locking system.
2. Create a new G2 Smart Relay 3 locking device.
3. Double-click on the SmartRelay 3 entry in the matrix to open the
settings.
4. Select the [IP settings] tab (see Establishing IP settings [} 23] for help
on IP settings).
5. Enter an IPv4 address.
6. Enter an IPv4 subnet mask.
7. Open the Communication nodes drop-down menu.
8. Select a suitable communication node. If you haven't yet created a
communication node for the service, you need to add one first. See
Creating a communication node [} 23].
Selecting the communication node
If you are using a CommNode server and a VN host server (use of tasks or
events in addition to the virtual network), then choose the CommNode
server entry here.
If you want to use a VN host server (use of the virtual network), then select
the VN host item here.
If you do not wish to use either, then select the GUI node item here.
9. Click on the Apply button.
10. Click on the Exit button.
6 | Setting up 20 / 135
