1.3 Main Specifications

1.3.1 Main Specifications
CPU
Configuration
Drive
Maximum cutting area
Guaranteed precision cutting area
Compatible film width
Maximum cutting speed
Specifiable speeds
Cutting pressure
Minimum character matrix
Mechanical resolution
Programmable resolution
Repeatability
Number of cutters/pens
Cutter and pen types
Compatible film
Standard interfaces
Buffer memory
Resident command sets
LCD panel
Compatible paper for pouncing
Power supply
Power consumption
Operating environment
Recommended environment
External dimensions
Weight
*1 When using Graphtec-specified film
*2 HP-GL is a trademark of Hewlett-Packard Company
*3 Use CB15U-K30 blades to cut sandblast rubber
16-bit
Grit-rolling cutting plotter
Digital servo
50 m x 580 mm
1
10 m x 580 mm *
50 to 635 mm (2 to 25 inches)
80 cm/s
21-step range (1 to 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 80
cm/s)
31-step range (5 to 300 g)
about 5 mm square (varies with the film and character font)
0.005 mm
GP-GL: 0.1/0.05/0.025/0.01 mm (selected by menu)
TM
HP-GL emulation mode: 0.025 mm *
Within 0.1 mm/2 m (excluding expansion or contraction caused by
changes in the operating environment)
1
Cutter blades: Super-steel, ceramic, and sapphire blades
Plotter pens: water and oil based, fiber-tip, water based ball-point,
ceramic, refillable ink, and disposable ink pens
Pouncing pen: 1.2 mm diameter pin
Mono-vinyl chloride film, fluorescent film, and film for illuminated
displays (highly-reflective film excluded), up to 0.25 mm thick
Sandblast rubber up to 1 mm thick *
RS-232C serial, Centronics compatible parallel (automatic interface
selection)
1 M byte
TM
GP-GL and HP-GL emulation (selected by menu)
20 characters x 2 lines; in six languages
Regular paper from 0.06 to 0.13 mm thick
100 to 120 VAC; 50/60 Hz
220 to 240 VAC; 50 Hz
120 VA max.
Temperature: +10°C to +35°C
Humidity: 35% to 75% RH (non-condensing)
Temperature: +16°C to +32°C
Humidity: 35% to 70% RH (non-condensing)
approx. 860 (W) x 622 (D) x 310 (H) mm
approx. 22 kg
