Holding Down the Film
(1) Raise the film lever to lower the push rollers onto the film to hold it in place.
Turning On the Power
(1) Turn on the plotter by pressing the "I" side of the power switch.
(2) Select the menu sequence required for your operation.
(3) Plotter initializes and the film loading is complete.
Note : For instructions on connecting the plotter to a power supply and selecting the film type, See
Section 4.1, "Turning On the Plotter."
Fig. 4-107
Fig. 4-108
