8.3 X Drive Section
No. Part Number
1 021601330
2 021601341
3 375311001
4 53501-001T
5 51407-046T
6 51407-047T
7 021601212
8 021601260
9 N/A
10 53520-003
11 51407-049T
12 310068820
13 52120-004
14 021601252
15 51407-017
16 51407-018
17 51407-026
18 51405-038
19 51405-023
20 509000044
21 508000009
22 52104-002
a
b
c
d
e
f
g
h
i
j
k
l
m
Description
Pulley X Drive Shaft
Pulley Drive Motor
Belt Drive Motor 120TN15-10W
Motor Drive UGJMEEA7MGR51
Panel Side Right
Panel Side Left
Stay Base
Roller Drive X-axis
Shaft Drive X-axis
Cutting Mat with Base
Bearing X Drive Shaft 688ZZ
Rivet Snap Dia:0.161"
Bearing Holder
Cover Air Left
Cover Air Right
Cover Air Duct
Collar X Drive Shaft
Bracket Media Sensor Right
Fan Suction 24V
Sensor Optical PSR11
Clamp Cable Dia:0.25"
Socket Set Screw
Socket Set Screw
Pan-head Screw with Flat Washer
Pan-head Thread Cutting Screw
Bind-head Screw
Pan-head Thread Forming Screw
Bind-head Screw
Pan-head Screw
N/A
N/A
Black Tape
Spring Lock Washer M3
Flat Washer M3
Remarks
Set of 4 grid rollers
with cable
M3 x L3
M3 x L5
M3 x L8
M4 x L12
M3 x L6
M4 x L8
M3 x L10
M3 x L30
8 - 5
FC3100-60 Service Manual
P/N53802-031T Rev. A
Q'ty Model
1 All
1 All
1 All
1 All
1 All
1 All
1 All
1 All
1 All
1 All
3 All
8 All
3 All
1 All
1 All
1 All
2 All
2 All
1 All
2 All
2 All
