CHAPTER 5 Specification

5.4 Accessories / Optional Accessories

Control Software GL-Connection (in STAND-ALONE mode only)

Item
Supported OS
Function
Number of groups
Number of CHs per 1 group
Maximum number of channels
Settings
Captured data
Display
Display modes
File conversion
Monitor functions
Statistic/History
E-mail function

Accessories

Item
Quick Start Guide
AC cable/AC adapter
Spacer
TO ENSURE SAFE AND CORRECT USE

Wireless LAN Unit B-568 (Option)

Item
Communication system
Installation location
Wireless LAN standard
Function
5-12
Windows10/Windows8.1/Windows8
Main unit control, realtime data capture, data conversion
4 groups MAX
Up to number of connected units
1000 ch maximun
AMP settings, capture settings, trigger/alarm settings, others
Realtime data (CSV, GBD Binary)
Data in Internal memory or SD CARD (CSV, GBD binary)
Analog waveforms, logic waveforms, pulse waveforms, digital values
Y-T View, Digital View, X-Y View, FFT View
Between cursors, All data
Alarm monitor enables sending of e-mail to the specified address
The e-mail is sent to the specified address when the alarm monitor is performed.
Alarm monitor enables sending of e-mail to the specified address
GLT400-UM-85x
100 to 240 VAC, 50/60 Hz
Large: 1, Small: 2 (Used when the terminal base is installed.)
SAFETY PAMPHLET
Wireless LAN
Insert into the SD CARD slot
* When the wireless unit is inserted, an SD CARD cannot be inserted into the SD CARD slot.
IEEE802.11b/g/n
Communication range: Approx. 40 m
* Communication range depends on the obstacles and the surrounding environmental conditions.
Control from PC, data transfer to PC (Connected as a remote unit of GL840 in REMOTE mode)
WPS : Push button method / PIN method
Encryption function : WEP64, WEP128, WPA-PSK/WPA 2-PSK, TKIP/AES
Description
Remarks
Description
Quantity
1
1
1 set
1
