Chapter 4 Using PAS Software

Downloading Setups to the Meter

Uploading Setups from the Meter

58
You can update each setup in your meter one at a time or
download all setups together from the site database.
Individual Download
To update a particular setup in your meter:
1. Check the On-line button on the PAS toolbar
2. Select a meter site from the list box on the toolbar.
3. Select the desired setup group from the Meter Setup
menu. Click on the setup tab you want to download to
the meter. As the setup dialog box opens, PAS
retrieves and displays the present meter setup data.
4. If you wish to download a setup saved in the site
database, click Open, and then click OK, or fill in the
boxes with the desired configuration data for your
device.
5. Click Send.
Batch Download
To download all setups to your device at once:
1. Check the On-line button on the toolbar
2. Select the device site from the list box on the toolbar.
3. Select Download Setups from the Meter Setup menu.
NOTE
The passwords setup is not downloaded via the Batch
Download. You can only download it individually via the
Administration Setup/Passwords
Meter Passwords in Chapter 5).
Individual Upload
To get a particular setup from your device;
1. Check the On-line button on the PAS toolbar.
2. Select a meter site from the list box on the toolbar,
and then select the desired setup group from the
Meter Setup menu.
3. Click on the tab of the setup you want to read from the
meter. As the dialog box opens, PAS retrieves and
displays the present setup data from the meter. Click
Receive if you wish to retrieve the meter setup once
again.
4. To store the setup to the meter site database, click
Save As, and then click OK.
Batch Upload
To upload all setups from the device to the site database at
once:
1. Check the On-line button on the toolbar.
EM720 Power Quality and Revenue Meter
Setting Up the Meter
dialog (see Configuring
