Chapter 8 Retrieving and Storing Files
Suspending the Scheduler
Running the Scheduler on Demand
Reviewing Upload Problems

Retrieving EN50160 Statistics Files

Using the Upload Scheduler
Retrieving EN50160 Statistics Files on Demand
Retrieving the EN50160 Online Statistics
EM720 Power Quality and Revenue Meter
To suspend the Upload Scheduler, check the Suspend
Scheduler box at right. To activate the Upload Scheduler,
leave this box unchecked.
You can run the scheduler at any time outside the schedule
by checking the Start Now box at right. This is a one-time
action. After uploading is completed, the Upload Scheduler
un-checks this box automatically.
When the Upload Scheduler fails to retrieve data from the
device, or some data is missing, or another problem occurs, it
puts an error message to the log file. To review this file,
select System Log from the View menu.
The EN50160 statistics files and present contents of the
EN50160 evaluation counters can be retrieved by PAS and
stored to a database for later analysis.
The PAS Upload
EN50160 statistics files on a daily or weekly basis depending
on the EN50160 evaluation period selected in your device.
Select the Daily or Weekly schedule for the EN50160
statistics files when configuring the upload schedule (see
Using the Upload Scheduler). Check the Data log #9 and #10
boxes in the Select Logs dialog box for uploading the
EN50160 Compliance Statistics and EN50160 Harmonics
Survey files respectively.
To manually retrieve the EN50160 statistics files on demand,
select "Upload EN50160 Compliance Stats" from the Logs
menu and specify the database to which you want the data to
be stored.
To retrieve the present contents of the EN50160 statistics
counters accumulated since the beginning of the current
evaluation period, select "Upload EN50160 Online Stats" from
the Logs menu and specify the database to which you want
the data to be stored. The statistics records are marked as
online events.
See Viewing EN50160 Statistics Reports
EN50160 compliance report for the latest online statistics
stored in the database.
Retrieving EN50160 Statistics Files
Scheduler automatically retrieves the
on how to get the
145
