Page 5 Introduction C H A P T E R AUSM Card Types Summary of AUSM Features Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 6: Table Of Contents
Managing Ports Displaying a List of Ports Displaying the Status of a Single Port Deleting Ports Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 7 4-20 addrscprtn 4-21 addspvc 4-23 aimhelp 4-27 chkflash 4-28 clear 4-29 clraimgrpcnt 4-30 clraimlncnt 4-31 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 8 4-62 cnfconstdabr 4-63 cnfilmi 4-65 cnfimaalmparm 4-67 cnfimagrp 4-68 cnfimatst 4-69 cnfln 4-70 cnflnloop 4-72 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 9 4-109 dspaimlncnt 4-110 dspalm 4-112 dspalmcnf 4-113 dspalmcnt 4-115 dspalms 4-117 dspautorestart 4-118 dspcd 4-119 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 10 4-159 dspportcnt 4-161 dspportq 4-163 dspportqs 4-164 dspportrscprtn 4-165 dspports 4-166 dsprscprtn 4-167 dspsarcnt 4-168 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 viii Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 11 4-184 setcmdc 4-185 setpagemode 4-186 tstcon 4-187 tstconseg 4-188 tstdelay 4-189 upcon 4-190 version 4-191 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 12 Contents Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 13 AUSM IMA and AIM Group Management Commands Table 4-6 AUSM Resource Partition Management Commands Table 4-7 AUSM Connection Management Commands Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 14 Tables Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 15: About This Book
MGX 8830 provides network operators and administrators who are responsible for MGX 8250, MGX8230, MGX 8850, or MGX8830 switches with information to set up ATM services, whether the Cisco WAN switch used is running a PXM1 card or a PXM1E card, which now provides Release 3 users access to narrowband service modules.
Page 16: Table 1 Cisco Wan Manager Release 11 Documentation
DOC-7811241= of the Cisco MGX 8250 Edge Concentrator. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 17: Table 3 Cisco Mgx 8850 (Pxm45) Multiservice Switch Release 3 Documentation
Cisco MGX 8950 switches with a PXM45 controller to operate as ATM edge or core switches. This guide also provides some DOC-7814788= operation and maintenance procedures. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 18 2. MIB = Management Information Base 3. SES = Service Expansion Shelf 4. VISM = Voice Interworking Service Module Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 19: Table 4 Cisco Mgx 8850 (Pxm1E) Multiservice Switch Release 3 Documentation
Also provides site preparation, troubleshooting, OL-2768-01 (online only) maintenance, cable and connector specifications, and basic Cisco IOS configuration information. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 xvii Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 20: Table 5 Cisco Mgx 8950 Multiservice Switch Release 3 Documentation
BPX 8600 switches. When connected to a PNNI network, each Cisco BPX 8600 Series Switch requires an SES for PNNI route processing. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 xviii Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 21: Table 6 Ses Pnni Controller Release 3 Documentation
Cisco BPX 8600 switches. When connected to a PNNI network, each Cisco BPX 8600 Series Switch requires an SES for PNNI route processing. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 22: Table 7 Cisco Mgx 8830 Multiservice Switch Release 3 Documentation
Cisco MGX 8830, Cisco MGX 8850 MGX 8950 Switches (PXM45 and PXM1E), and Cisco MGX 8950 switches. DOC-7814790= Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 23: Table 8 Cisco Wan Switching Software Release 9.3 Documentation
Cisco MGX 8800 Series Switch System Error Messages, Provides error message descriptions and recovery procedures. Release 1.1.3 DOC-7811240= Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 24: Table 10 Cisco Mgx 8250 Edge Concentrator Switch Release 1 Documentation
Describes the system components and functionality of the Cisco Release 1.1.3 MGX 8250 Edge Concentrator Switch from a technical perspective. DOC-7811576= Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 xxii Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 25: Table 11 Cisco Mgx 8230 Edge Concentrator Switch Release 1 Documentation
Cisco IOS configuration information. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 xxiii Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 26 Timesaver. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 xxiv Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 27: Obtaining Documentation
Obtaining Documentation These sections explain how to obtain documentation from Cisco Systems. World Wide Web You can access the most current Cisco documentation on the World Wide Web at this URL: http://www.cisco.com Translated documentation is available at this URL: http://www.cisco.com/public/countries_languages.shtml...
Page 28: Documentation Feedback
Order Cisco learning materials and merchandise • Register for online skill assessment, training, and certification programs If you want to obtain customized information and service, you can self-register on Cisco.com. To access Cisco.com, go to this URL: http://www.cisco.com Technical Assistance Center The Cisco Technical Assistance Center (TAC) is available to all customers who need technical assistance with a Cisco product, technology, or solution.
Page 29 Cisco TAC Web Site You can use the Cisco TAC Web Site to resolve P3 and P4 issues yourself, saving both cost and time. The site provides around-the-clock access to online tools, knowledge bases, and software. To access the Cisco TAC Web Site, go to this URL: http://www.cisco.com/tac...
Page 30 About This Book Obtaining Technical Assistance Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 xxviii Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 31: Table 1-1 Ausm Card Types Supported By Pxm1E Controllers
RJ48-8E1-R, SMB-8E1-R The preferred tools to configure, monitor, and control service modules are the CiscoView and Cisco WAN Manager applications for equipment management and connection management. (The Cisco WAN Manager application is the former Cisco StrataView Plus application with the equipment management removed.) However, the command-line interface (CLI) also provides access the service modules and is...
Page 32 SNMP and TFTP to support card and connection management. • Resource partitions for individual network control applications. • Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 33: Chapter 2 Provisioning Communications Links
The easiest way to add connections is by using the Cisco WAN Manager application. For full details Note on how to set up a connection through the Cisco WAN Manager GUI, refer to the Cisco WAN Manager User’s Guide. This chapter explains how to provision the link and connection types described in Table 2-1.
Page 34: Preparing For Provisioning
Otherwise, you may have to change your configuration later to support these options. For instructions on initializing cards and configuring card and line redundancy, refer to the Cisco MGX 8850 (PXM1E) and MGX 883Cisco MGX 8850 (PXM1E) and MGX 8830 Software Configuration Guide, Release 3.
Page 35: Line Configuration Quickstart
<port> devices. dspports See the “Adding ATM Ports” section that appears later in this chapter. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 36: Ima Group Configuration Quickstart
PNNI protocol reroutes that link to maintain the connection and to supply the necessary bandwidth. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 37: Ausm-To-Non-Ausm Spvc Configuration Quickstart
The difference is that you will have to refer to the documentation for the non-AUSM product for information on configuring the connection endpoint. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 38 If the master side of the connection is on a non-AUSM card, refer to the documentation for that card. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 39: General Ausm Provisioning Procedures
AUSM Card Types Front Card Valid Line Numbers AUSM-8T1/B 1 to 8 AUSM-8E1/B 1 to 8 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 40: Configuring Lines
Remember that you cannot configure a line until you have brought it up, as described earlier in the “Bringing Up Lines” section. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 41: Table 2-3 Line Parameters For The Cnfln Command
• E1 (with SMB line module) = 8 • E1 (with RJ48 line module) = 9 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 42: Adding Atm Ports
Line alarm 3622 Line alarm 3622 Line alarm 3622 Line alarm List of IMA groups: =================== Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-10 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 43: Table 2-4 Parameters For The Addport Command
The following addport command example defines ATM port 7 as a UNI port on line 7. PXM1E_SJ.1.1.AUSMB8.a > addport 7 1 7 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-11 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 44: Adding Ima Groups
ATM Inverse Multiplexing (AIM) is an older term that refers to the same features supported Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-12...
Page 45: Table 2-5 Parameters For Addimagrp Command
--------------- --------- ---------- 14364 14364 1.2.3.4 1.2.3.4 Active 14364 5.6.7.8 Sig. Failure NextPortNumAvailable: PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-13 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 46: Configuring Ima Groups
T1 and E1 lines on an AUSM card. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-14 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 47: Configuring Spvcs On Ausm Cards
Configuring SPVCs on AUSM Cards SPVCs can be added and modified through the Cisco WAN Manager or the CLI. Refer to applicable documentation if you use the Cisco WAN Manager application. AUSM SPVCs are created between one ATM port and another ATM port. Each SPVC has two endpoints.
Page 48: Configuring The Slave Side Of Spvcs
Once you create an SPVC connection, you cannot change the SPVC prefix until all SPVC connections have been deleted. The procedure for changing the SPVC prefix is described in the Cisco MGX 8850 (PXM1E) and MGX 883Cisco MGX 8850 (PXM1E) and MGX 8830 Software Configuration Guide, Release 3.
Page 49 Peak cell rate for ABR connections. The range is 10 to 38328 cps. -abrmcr Minimum cell rate for ABR connections. The range is 10 to 38328 cps. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-17 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 50 IMA group rate = ATM port rate x #links • -cbs Enter the maximum burst size. The range is 1 to 5000 cells. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-18 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 51 ATM address now, you can use the session Paste command to complete the addcon command on the switch that hosts the master side of the SPVC. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-19...
Page 52 PeakCellRate[0](cells/sec): 3591 CellDelayVariation[0]: 250000 (micro secs) SustainedCellRate(cells/sec): MaximumBurstSize(cells): 1024 SCRPolicing: CLP[0] CLPTagEnable: Enabled FrameGCRAEnable: Disable Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-20 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 53 Cutoff Decrease Factor: AbrType: Switch behavior without VS/VD ChanNumNextAvailable Local VpId NextAvailable : PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-21 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 54: Configuring The Master Side Of Spvcs
Note controller has not been added on the PXM1E card. For information on adding the PNNI controller, refer to the Cisco MGX 8850 (PXM1E) and MGX 883Cisco MGX 8850 (PXM1E) and MGX 8830 Software Configuration Guide, Release 3. Table 2-7 lists and describes the parameters for the addcon command.
Page 55 FrameGCRAEnable: Disable InitialBurstSize(cells): LocalRemoteLpbkState: Disable ChanTestType: No Test ChanTestState: Not In Progress ChanRTDresult: 65535 ms Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-23 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 56 500 milliseconds Cutoff Decrease Factor: AbrType: Switch behavior without VS/VD ChanNumNextAvailable Local VpId NextAvailable : Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 2-24 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 57: Chapter 3 Ausm Card Management
This chapter provides procedures for managing AUSM-8T1/Band AUSM-8E1 cards after the initial card setup and provisioning. Initial card setup is described in the Cisco MGX 8850 (PXM1E) and MGX 883Cisco MGX 8850 Note (PXM1E) and MGX 8830 Software Configuration Guide, Release 3. The provisioning of AUSM cards is described in Chapter 2, “Provisioning Communications Links.”...
Page 58: Managing Cards
Managing Cards Basic card initialization and configuration is described in the Cisco MGX 8850 (PXM1E) and MGX 883Cisco MGX 8850 (PXM1E) and MGX 8830 Software Configuration Guide, Release 3. The following sections provide procedures for doing the following: •...
Page 59: Displaying General Card Information
Program length = 377836 Calculated checksum = 3818c59a stored checksum = 3818c59a Flash checksum passed PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 60: Managing Lines
RJ-48 dsx1ESF Dis/dsx1B8ZS 0-131 ft LocalTim 21.8 RJ-48 dsx1ESF Mod/dsx1B8ZS 0-131 ft LoopTimi LineNumOfValidEntries: 8 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 61: Display The Configuration For A Single Line
Delete all ports that are associated with the line (delport command). Step 3 Step 4 Enter the delln command as follows: PXM1E_SJ.1.21.AUSMB8.a > delln <line> Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 62: Managing Line Alarms
---- -------- ----- ---------- ----- --------- 3622 Line alarm 3622 Line alarm 3622 Line alarm 3622 Line alarm Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 63: Displaying The Status Of A Single Port
The next example shows the report for an ATM port number that is assigned to an IMA group. This is the same report that appears when you enter the dspimagrp command. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 64: Deleting Ports
Replace the port parameter with the port number you want to delete. Port numbers are listed in the dspports command display. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 65: Managing Ima Groups
: Enabled IMA Port state : Active IMA Group Ne state : operational PortSpeed (cells/sec) : 14364 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 66: Adding Lines To An Ima Group
To delete one or more lines from an IMA group, enter the dellnsfmimagrp command as follows: PXM1E_SJ.1.1.AUSMB8.a > dellnsfmimagrp <group_num> <list_of_lines> Table 3-2 describes the parameters for this command. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 3-10 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 67: Deleting An Ima Group
IMA group is added. This resource assignment is automatically made by the software and results in the creation of a resource partition for the port. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 3-11...
Page 68: Displaying A Resource Partition Configuration
Enter the maximum VPI number to allow for connections using the specified controller type (cntrlr_type) on this port. The range is from 0 to 255. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 3-12...
Page 69: Modifying A Resource Partition
The port number shown in the dspcons display is the resource partition number. Step 2 Enter the delrscprtn command as follows: PXM1E_SJ.1.1.AUSMB8.a > delrscprtn <port> <cntrlr_type> <cntrlr_id> Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 3-13 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 70: Managing Connections
VCI numbers in the dspcons display. The following example shows the dspcon report for connection 100/100 on port 1: Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 3-14 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 71 Mastership: Slave VpcFlag: RoutingPriority: MaxCost: 2147483647 RestrictTrunkType: No Restriction LocalConnPCR: 3591 LocalConnSCR: LocalConnMCR: RemoteConnPCR: 3591 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 3-15 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 72: Deleting Connections
Enter the connection port number, VPI, and VCI with the command. You can view the port, VPI, and VCI numbers in the dspcons display. The following is an example of a tstcon test: Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 3-16...
Page 73: Testing With Tstdelay
PXM1E_SJ.1.4.AUSMB8.a > tstdelay 1.100.100 PXM1E_SJ.1.4.AUSMB8.a > TestDelay in progress. TestDelay Passed with 1 ms. PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 3-17 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 74 Chapter 3 AUSM Card Management Managing Connections Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 3-18 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 75: Table 4-1 Ausm Session Management Commands
Table 4-1 AUSM Session Management Commands Command AUSM-8T1/B AUSM-8E1 aimhelp clear clrscrn Help myid setcmdc setpagemode Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 76: Table 4-2 Ausm Card Management Commands
Command AUSM-8T1/B AUSM-8E1 addln addlnloop clralm clralmcnt clralmcnts clralms cnfln cnflnloop cnfplpp delln dellnloop dspalm dspalmcnf Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 77: Table 4-4 Ausm Port Management Commands
AIM Command AUSM-8T1/B AUSM-8E1 addimagrp addaimgrp addlns2imagrp addlns2aimgrp clrimagrpcnt clraimgrpcnt clrimalncnt clraimlncnt clrimatst cnfautorestart cnfimagrp cnfaimgrp cnfimaalmparm Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 78 AUSM Resource Partition Management Commands Command AUSM-8T1/B AUSM-8E1 addrscprtn cnfcdrscprtn cnfportrscprtn cnfrscprtn delcdrscprtn delrscprtn dspcdrscprtn dspportrscprtn dsprscprtn Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 79: Table 4-7 Ausm Connection Management Commands
Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 80 AUSM Command Reference Table 4-7 AUSM Connection Management Commands (continued) Command AUSM-8T1/B AUSM-8E1 tstcon tstconseg tstdelay upcon Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 81 Active Group 1 clralm Group 5 clralmcnt Group 5 Type <CR> to continue, Q<CR> to stop: Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 82: Addaimgrp
The following example creates an NNI IMA group 1 with lines 1, 2, 3 and 4. The minimum number of lines is 3. PXM1E_SJ.1.1.AUSMB8.a > addaimgrp 1 2 1.2.3.4 3 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 83: Addchanloop
The next example adds a channel loop by specifying the port, VPI, and VCI numbers. PXM1E_SJ.1.4.AUSMB8.a > addchanloop 1.100.100 PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 84: Addcon
Note controller has not been added on the PXM1E card. For information on adding the PNNI controller, refer to the Cisco MGX 8850 (PXM1E) and MGX 883Cisco MGX 8850 (PXM1E) and MGX 8830 Software Configuration Guide, Release 3. Syntax Description...
Page 85 -epcu Egress percent utilization. Range is 1 to 100 percent. Default setting is 100 percent. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-11 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 86 Multiply the single line rate by the number of lines. -cbs Enter the maximum burst size. The range is 1 to 5000 cells. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-12 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 87 Remote maximum burst size. Range is 1 to 5,000,000. Related Commands cnfcon, delcon, dncon, dspcon, dspcons. rrtcon, tstcon, upcon Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-13 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 88 Local Connection ID shown at the end of the display. PXM1E_SJ.1.4.AUSMB8.a > addcon 1 100 100 Local Connection Id is : 4700918100000000016444445c00000101230100.100.100 PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-14 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 89: Addimagrp
The following example creates an NNI IMA group 1 with lines 1, 2, 3 and 4. The minimum number of lines is 3. PXM1E_SJ.1.1.AUSMB8.a > addimagrp 1 2 1.2.3.4 3 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-15 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 90: Addln
Example Bring up line 8 on an AUSM-8T1/B card. PXM1E_SJ.1.21.AUSMB8.a > addln 8 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-16 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 91: Addlnloop
Place line 8 on the AUSM card in loopback mode. PXM1E_SJ.1.21.AUSMB8.a > addlnloop 8 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-17 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 92: Addlns2Aimgrp
The next example shows how to add multiple lines to an IMA group. PXM1E_SJ.1.1.AUSMB8.a > addlns2aimgrp 1 7.8 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-18 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 93: Addlns2Imagrp
The next example shows how to add multiple lines to an IMA group. PXM1E_SJ.1.1.AUSMB8.a > addlns2imagrp 1 7.8 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-19 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 94: Addport
Add port 8 to line 8 and define the port as a UNI port. PXM1E_SJ.1.21.AUSMB8.a > addport 8 1 8 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-20 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 95: Addrscprtn
Enter a number that will be associated with the controller used by this partition. Range is 1 to 255. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-21 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 96 Several specifications reserve VCI values in the range of 0 through 35. If you are not familiar with these specifications and want to avoid potential conflicts, set the lower VCI value to 35. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-22...
Page 97: Addspvc
Controller type. Select one of the following: 1 = PAR • • 2 = PNNI (default) • 3 = MPLS Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-23 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 98 This option only applies to the following service class types (-st option): CBR (1), nrtVBR (2), ABR (3), UBR (4), and rtVBR (5). Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-24 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 99 IMA group rate = ATM port rate x #links -rcbs Remote maximum burst size. Range is 1 to 5,000,000. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-25 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 100 Local Connection ID shown at the end of the display. PXM1E_SJ.1.4.AUSMB8.a > addspvc 1 100 100 Local Connection Id is : 4700918100000000016444445c00000101230100.100.100 PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-26 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 101: Aimhelp
Clear self test results clrimatst clear IMA test procedure Type <CR> to continue, Q<CR> to stop: Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-27 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 102: Chkflash
Program length = 377836 Calculated checksum = 3818c59a stored checksum = 3818c59a Flash checksum passed PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-28 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 103: Clear
After you enter the clear command, the only text that appears on the screen is the CLI prompt. PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-29 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 104: Clraimgrpcnt
Clear the failure count for IMA group 1 on the current card. PXM1E_SJ.1.1.AUSMB8.a > clraimgrpcnt 1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-30 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 105: Clraimlncnt
Clear the line counters for line 1 in IMA group 1. PXM1E_SJ.1.1.AUSMB8.a > clraimlncnt 1 1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-31 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 106: Clralm
Clear the active alarms for line 2 on the current AUSM card. PXM1E_SJ.1.21.AUSMB8.a > clralm -ds1 2 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-32 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 107: Clralmcnt
Clear the alarm counters for line 2 on the current AUSM card. PXM1E_SJ.1.21.AUSMB8.a > clralmcnt -ds1 2 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-33 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 108: Clralmcnts
Clear the alarm counters for all lines on the current AUSM card. PXM1E_SJ.1.21.AUSMB8.a > clralmcnts PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-34 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 109: Clralms
Clear the active alarms for all lines on the current AUSM card. PXM1E_SJ.1.21.AUSMB8.a > clralms PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-35 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 110: Clrcderrs
Clear all card-related errors on the AUSM in slot 21. PXM1E_SJ.1.21.AUSMB8.a > clrcderrs PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-36 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 111: Clrchancnt
Privilege: Group 5 Example Clear the statistics for channel 19. PXM1E_SJ.1.21.AUSMB8.a > clrchancnt 19 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-37 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 112: Clrchancnts
Clear the statistics for all channels on the AUSM card in slot 21. PXM1E_SJ.1.21.AUSMB8.a > clrchancnts PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-38 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 113: Clrimagrpcnt
Clear the failure count for IMA group 1 on the current card. PXM1E_SJ.1.1.AUSMB8.a > clrimagrpcnt 1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-39 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 114: Clrimalncnt
Clear the line counters for line 1 in IMA group 1. PXM1E_SJ.1.1.AUSMB8.a > clrimalncnt 1 1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-40 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 115: Clrimatst
Clear the IMA test feature for IMA group 1. PXM1E_SJ.1.1.AUSMB8.a > clrimatst 1 1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-41 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 116: Clrmsgcnt
Example Clear the message counters for the current AUSM card. PXM1E_SJ.1.21.AUSMB8.a > clrmsgcnt PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-42 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 117: Clrportcnt
Clear the counters on port 1 of the current AUSM card. PXM1E_SJ.1.1.AUSMB8.a > clrportcnt 1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-43 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 118: Clrportcnts
Clear the counters on all ports of the current AUSM card. PXM1E_SJ.1.1.AUSMB8.a > clrportcnts PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-44 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 119: Clrsarcnt
Clear the SAR counters for the connection on port 1 with VPI/VCI 100/100. PXM1E_SJ.1.13.AUSMB8.a > clrsarcnt 1 100 100 PXM1E_SJ.1.13.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-45 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 120: Clrsarcnts
Example Clear the SAR counters on the current AUSM card. PXM1E_SJ.1.13.AUSMB8.a > clrsarcnts PXM1E_SJ.1.13.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-46 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 121: Clrscrn
After you enter the clrscrn command, the only text that appears on the screen is the CLI prompt. PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-47 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 122: Clrslftst
Example Clear the self test table for the current card. PXM1E_SJ.1.21.AUSMB8.a > clrslftst PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-48 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 123: Clrtaskinfo
State: Any Privilege: Service Group Example Clear the task information counters. PXM1E_SJ.1.21.AUSMB8.a > clrtaskinfo PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-49 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 124: Cls
After you enter the cls command, the only text that appears on the screen is the CLI prompt. PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-50 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 125: Cnfaimgrp
Configure IMA group 1 for the default 275 ms maximum differential delay, and set the minimum number of lines to 2. PXM1E_SJ.1.1.AUSMB8.a > cnfaimgrp 1 275 2 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-51 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 126: Cnfautorestart
Privilege: Group 1 Example Enable the IMA group automatic restart feature. PXM1E_SJ.1.1.AUSMB8.a > cnfautorestart 2 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-52 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 127: Cnfcdprtntype
Port controller based = 3 • Related Commands dspcdprtntype Attributes Log: Yes State: Active Privilege: Group 2 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-53 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 128: Cnfcdrscprtn
Configure the card resource partition to use the maximum number of LCNs on new ports and IMA groups. PXM1E_SJ.1.1.AUSMB8.a > cnfcdrscprtn 1000 1000 1000 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-54 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 129: Cnfchan
Multiply the single line rate by the number of lines. PctUtil Percent utilization. Range is 1 to 100 percent. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-55 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 130 Related Commands addcon, delcon, dspcon, dspcons Attributes Log: Yes State: Active Privilege: Group 2 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-56 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 131: Cnfchanq
Attributes Log: Yes State: Active Privilege: Group 2 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-57 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 132: Cnfcon
An IMA group’s range depends on the number of links in the group. Note Multiply the single line rate by the number of lines. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-58 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 133 Percent utilization. Range is 1 to 100 percent. Related Commands addcon, delcon, dspcon, dspcons Attributes Log: Yes State: Active Privilege: Group 2 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-59 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 134: Cnfconabrparams
RM cell returns. Range: 0–16777215 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-60 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 135 Configure the ABR parameters on connection 27. pxmsjc.1.11.AUSMB8.a > cnfconabrparams 27 2 64 16 64 200 16777215 100 500 16 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-61 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 136: Cnfconabrrates
Example Configure the ABR parameters on connection 27. pxmsjc.1.11.AUSMB8.a > cnfconabrrates 27 20 1600 500 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-62 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 137: Cnfconstdabr
Rate decrease factor controls the decrease in the cell transmission rate. RDF is a power of 2 from 1/32768 to 1. Range: 1–32768 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-63 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 138 TM 4.0 specification. pxmsjc.1.11.AUSMB8.a > cnfconstdabr 27 2 10 1500 100 128 16 64 255 16777215 0 500 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-64 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 139: Cnfilmi
To disable this feature, enter 1. Related Commands dspilmi, dspilmicnt Attributes Log: Yes State: Active Privilege: Group 1 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-65 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 140 Enable ILMI signaling, traps, keep alive polling, and address registration for port 1 on the AUSM. PXM1E_SJ.1.1.AUSMB8.a > cnfilmi 1 3 0 16 2 1 2 2 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-66 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 141: Cnfimaalmparm
Configure the IMA alarm parameters for group 1 to the default values. PXM1E_SJ.1.1.AUSMB8.a > cnfimaalmparm 1 2500 10000 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-67 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 142: Cnfimagrp
Configure IMA group 1 for the default 275 ms maximum differential delay, and set the minimum number of lines to 2. PXM1E_SJ.1.1.AUSMB8.a > cnfimagrp 1 275 2 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-68 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 143: Cnfimatst
Configure the IMA test feature for IMA group 1, line 1 to use test pattern 5. PXM1E_SJ.1.1.AUSMB8.a > cnfimatst 1 1 5 2 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-69 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 144: Cnfln
CCS, with CRC = CCS_CRC Clear E1 = CLEAR • Related Commands addln, delln, dspln, dsplns Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-70 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 145 Configure line 8 to use B8ZS line coding on a line length between 0 to 131 feet, and configure the line for loop clock. PXM1E_SJ.1.21.AUSMB8.a > cnfln 8 2 10 1 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-71 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 146: Cnflnloop
Enable code detection for line 8 in loopback mode. PXM1E_SJ.1.21.AUSMB8.a > cnflnloop 8 2 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-72 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 147: Cnfplpp
JANUS_MERGE.1.21.AUSMB8.a > cnfplpp 8 1 1 2 JANUS_MERGE.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-73 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 148: Cnfportq
Range: 1–16000 cells Related Commands dspportq, dspportqs Attributes Log: Yes State: Active Privilege: Strata Group Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-74 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 149 Enter the dspportq command before the cnfportq command so you can easily copy port queue parameters that you do not want to change. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-75 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 150: Cnfportrscprtn
Maximum LCN to be used on this port. Range is 1 to 1000. Related Commands addrscprtn, delrscprtn, dspportrscprtn, dsprscprtn Attributes Log: Yes State: Active Privilege: Group 1 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-76 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 151 PXM1E_SJ.1.1.AUSMB8.a > cnfportrscprtn 1 PNNI 100 0 255 16 65535 1 1000 1000 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-77 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 152: Cnfrscprtn
Enter a number that will be associated with the controller used by this partition. Range is 1 to 255. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-78 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 153 Several specifications reserve VCI values in the range of 0 through 35. If you are not familiar with these specifications and want to avoid potential conflicts, set the lower VCI value to 35. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-79...
Page 154: Cnfslftst
The following example enables self testing and configures the testing to repeat every minute. PXM1E_SJ.1.21.AUSMB8.a > cnfslftst -en 2 -tm 1 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-80 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 155: Cnfupcabr
Minimum Cell Rate (MCR) to be used for standard ABR traffic. The range is: 10 to pcr[0+1]. To retain the current value, enter 0. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-81...
Page 156 PXM1E_SJ.1.13.AUSMB8.a > cnfupcabr 16 2 3622 10000 0 1 1024 100 3622 100 2 PXM1E_SJ.1.13.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-82 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 157: Cnfupccbr
Enter the Cell Delay Variation Tolerance for cells with CLP = 0 and CLP = 1. The range is 1 to 250000 microseconds. IngPcUtil Ingress percentage utilization. Range: 1–127 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-83 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 158 AUSM (using channel number argument). s1.1.12.AUSMB8.a > cnfupccbr 21 2 4528 250000 50 4528 50 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-84 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 159: Cnfupcrtvbr
Enter the Cell Delay Variation Tolerance for cells with CLP = 0 and CLP = 1. The range is 1 to 250000 microseconds. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-85 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 160 CBR (1), nrtVBR (2), ABR (3), UBR (4), and rtVBR (5). Related Commands dspcon, dspcons Attributes Log: Yes State: Active Privilege: Group 2 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-86 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 161: Cnfupcubr
This option only applies to the following service class types (-st option): Note CBR (1), nrtVBR (2), ABR (3), UBR (4), and rtVBR (5). Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-87 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 162 Configure the usage parameter control (UPC) parameters for UBR on the current AUSM. s1.1.12.AUSMB8.a > cnfupcubr 2.1.7 2 4528 250000 50 2 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-88 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 163: Cnfupcvbr
Minimum Cell Rate (MCR) to be used for standard ABR traffic. The range is: 10 to pcr[0+1]. To retain the current value, enter 0. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-89...
Page 164 AUSM. s1.1.12.AUSMB8.a > cnfupcvbr 2.1.3 2 3000 250000 2000 1 1000 50 4000 50 2 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-90 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 165: Copychans
(VCI) for the connections you are creating. Related Commands addcon, delchan, delchans Attributes Log: Yes State: Active Privilege: Group 1 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-91 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 166: Delaimgrp
Privilege: Group 1 Example The following example deletes IMA group 1: PXM1E_SJ.1.1.AUSMB8.a > delaimgrp 1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-92 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 167: Delcdrscprtn
Delete the LCN count for the PAR controller on the current AUSM card. PXM1E_SJ.1.1.AUSMB8.a > delcdrscprtn 1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-93 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 168: Delchan
Privilege: Group 2 Example Delete the connection with LCN 16. PXM1E_SJ.1.1.AUSMB8.a > delchan 16 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-94 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 169: Delchanloop
Remove channel loopback from channel 16 on the current AUSM card. PXM1E_SJ.1.4.AUSMB8.a > delchanloop 16 PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-95 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 170: Delchans
Delete channels 16 through 17 on the current card. PXM1E_SJ.1.4.AUSMB8.a > delchans 16 2 PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-96 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 171: Delcon
Privilege: Group 2 Example Delete connection 100/100 from port 1. PXM1E_SJ.1.4.AUSMB8.a > delcon 1.100.100 PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-97 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 172: Delimagrp
Privilege: Group 1 Example The following example deletes IMA group 1: PXM1E_SJ.1.1.AUSMB8.a > delimagrp 1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-98 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 173: Delln
Example Bring down line 8 on an AUSM card. PXM1E_SJ.1.21.AUSMB8.a > delln 8 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-99 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 174: Dellnloop
Remove line loopback from line 8 on an AUSM card. PXM1E_SJ.1.21.AUSMB8.a > dellnloop 8 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-100 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 175: Dellnsfmaimgrp
Warning: If Connections exist under the ima group then the cell rates might require modification PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-101 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 176: Dellnsfmimagrp
Warning: If Connections exist under the ima group then the cell rates might require modification PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-102 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 177: Delport
Privilege: Group 1 Example Delete port 8 on an AUSM card. PXM1E_SJ.1.1.AUSMB8.a > delport 8 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-103 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 178: Delrscprtn
The following example deletes a PNNI resource partition from port 1. PXM1E_SJ.1.1.AUSMB8.a > delrscprtn 1 2 2 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-104 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 179: Dncon
Privilege: Group 1 Example Bring down the connection on channel 19. PXM1E_SJ.1.4.AUSMB8.a > dncon 19 PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-105 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 180: Dspaimgrp
Related Commands addaimgrp, addlns2aimgrp, cnfaimgrp, delaimgrp, dellnsfmaimgrp, dspaimgrps Attributes Log: No State: Active Privilege: Group 1 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-106 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 181 IMAGrp Failure status : No Failure Timing reference link ImaGroupTxImaId : 0x0 ExpectedGroupRxImaId : 0x0 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-107 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 182: Dspaimgrpcnt
Display the failure count for IMA group 2 on the current card. PXM1E_SJ.1.1.AUSMB8.a > dspaimgrpcnt 2 IMA Group number: Ne Number of failures PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-108 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 183: Dspaimgrps
--------------- --------- ---------- 14364 14364 1.2.3.4 1.2.3.4 Active 14364 5.6.7.8 Sig. Failure NextPortNumAvailable: PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-109 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 184: Dspaimlncnt
Related Commands clraimgrpcnt, clraimlncnt, dspaimgrp, dspaimgrpcnt, dspaimgrps, dspimainfo Attributes Log: No State: Active Privilege: Group 1 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-110 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 185 IMA group number -- value ranging from 1 to 8 line number -- value ranging from 1 to 8 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-111 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 186: Dspalm
PXM1E_SJ.1.21.AUSMB8.a > dspalm -ds1 8 LineNum: LineAlarmState: No Alarms LineStatisticalAlarmState: No Statistical Alarms PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-112 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 187: Dspalmcnf
Related Commands None Attributes Log: No State: Any Privilege: Any User Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-113 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 188 Type <CR> to continue, Q<CR> to stop: cRCSES24hrThreshold: SEFS15minThreshold: SEFS24hrThreshold: AISS15minThreshold: AISS24hrThreshold: UAS15minThreshold: UAS24hrThreshold: PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-114 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 189: Dspalmcnt
Related Commands clralmcnt Attributes Log: No State: Any Privilege: Any User Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-115 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 190 Type <CR> to continue, Q<CR> to stop: sEFSLast24hrBucket: aISSCurrent: aISSLast15minBucket: aISSLast24hrBucket: uASCurrent: uASLast15minBucket: uASLast24hrBucket: percentEFS: RcvLOSCount: RcvOOFCount: RcvRAICount: RcvFECount: PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-116 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 191: Dspalms
----------- --------------------- 21.1 Alarm(s) On Alarm(s) On 21.8 No Alarms No Statistical Alarms PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-117 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 192: Dspautorestart
Display the IMA group automatic restart feature setting. PXM1E_SJ.1.1.AUSMB8.a > dspautorestart IMA Group Auto Restart Feature : DISABLE PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-118 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 193: Dspcd
AUSM card. Syntax Description None Related Commands version Attributes Log: No State: Any Privilege: Any User Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-119 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 194 Back Card Info Hardware Revision Card Type Serial Number 773224 Fab Number 28-2011-01 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-120 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 195: Dspcderrs
Example Display any card errors for the current AUSM card. PXM1E_SJ.1.21.AUSMB8.a > dspcderrs PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-121 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 196: Dspcdprtntype
Syntax Description None. Related Commands cnfcdprtntype Attributes Log: Yes State: Active Privilege: Group 2 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-122 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 197: Dspcdrscprtn
Display card resource partition configuration information for the current AUSM card. PXM1E_SJ.1.1.AUSMB8.a > dspcdrscprtn User NumOfLcnAvail ------ ------------- 1000 PNNI 1000 1000 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-123 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 198: Dspchan
Attributes Log: No State: Any Privilege: Any User Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-124 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 199 LocalNSAP: 4700918100000000016444445c000001016b0200 RemoteVpi: RemoteVci: RemoteNSAP: 4700918100000000016444445c000001015b0400 Mastership: Master VpcFlag: RoutingPriority: MaxCost: 2147483647 RestrictTrunkType: No Restriction Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-125 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 200 Cutoff Decrease Factor: AbrType: Switch behavior without VS/VD ChanNumNextAvailable Local VpId NextAvailable : PXM1E_SJ.1.13.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-126 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 201: Dspchancnt
Attributes Log: No State: Any Privilege: Any User Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-127 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 202 3004 ChanIngressReceiveUtilization(percentage): ChanIngressTransmitCellRate(cells/sec): 3004 ChanIngressTransmitUtilization(percentage): 82 ChanEgressReceiveCellRate(cells/sec): ChanEgressReceiveUtilization(percentage): EgressPortQFullDiscardCells: EgressPortQClpThreshDiscardCells: ChanTransmitFifoFullCount (per card): PXM1E_SJ.1.13.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-128 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 203: Dspchans
• • RT-VBR3 • NRT-VBR1 • NRT-VBR2 • NRT-VBR3 • UBR1 UBR2 • ABRSD • Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-129 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 204 Attributes Log: No State: Any Privilege: Any User Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-130 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 205 0017 002 100 00100 CBR1 PORT-ALARM Number of channels: ChanNumNextAvailable Local VpId NextAvailable : PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-131 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 206: Dspcon
ServiceType: CBR1 ChanSvcFlag: PNNI PortNum: VPI: VCI (For VCC): Local VPId(for VPC): EgressQNum: IngressQDepth(cells): 1000 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-132 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 207 0 milliseconds ACR Decrease Time Factor: 500 milliseconds Cutoff Decrease Factor: AbrType: Switch behavior without VS/VD Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-133 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 208 Chapter 4 AUSM Command Reference dspcon ChanNumNextAvailable Local VpId NextAvailable : PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-134 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 209: Dspcons
• • RT-VBR3 • NRT-VBR1 • NRT-VBR2 • NRT-VBR3 • UBR1 UBR2 • ABRSD • Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-135 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 210 Attributes Log: No State: Any Privilege: Any User Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-136 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 211 0017 002 100 00100 CBR1 PORT-ALARM Number of channels: ChanNumNextAvailable Local VpId NextAvailable : PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-137 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 212: Dspconstdabr
ACR Decrease Time Factor 500 milliseconds Cutoff Decrease Factor ABRType Switch behavior without VS/VD PXM1E_SJ.1.13.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-138 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 213: Dspfeature
Display features of the current AUSM card. PXM1E_SJ.1.21.AUSMB8.a > dspfeature Rate Control: IMA feature: PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-139 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 214: Dspilmi
SignallingVPI: SignallingVCI: ILMITrap: Disable ILMI-Min-Trap-Interval(secs): KeepAlivePolling: Disable ErrorThreshold: EventThreshold: PollingInterval(secs): MinimumEnquiryInterval(secs): AddressRegistration: Disable PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-140 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 215: Dspilmicnt
SNMPPDUsReceived: GetRequestReceived: GetNextRequestReceived: SetRequestReceived: TrapReceived: GetResponseReceived: GetResponseTransmitted: GetRequestTransmitted: TrapsTransmitted: InvalidPDUReceived: Asn1ParseError: NoSuchNameError: TooBigError: PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-141 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 216: Dspimaalmparm
PXM1E_SJ.1.1.AUSMB8.a > dspimaalmparm 1 Group No. UpTime(msec). DownTime(msec) --------- ------- -------------- 2500 10000 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-142 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 217: Dspimagrp
IMAGrp Failure status : No Failure Timing reference link ImaGroupTxImaId : 0x0 ExpectedGroupRxImaId : 0x0 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-143 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 218: Dspimagrpcnt
Display the failure count for IMA group 2 on the current card. PXM1E_SJ.1.1.AUSMB8.a > dspimagrpcnt 2 IMA Group number: Ne Number of failures PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-144 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 219: Dspimagrps
--------------- --------- ---------- 14364 14364 1.2.3.4 1.2.3.4 Active 14364 5.6.7.8 Sig. Failure NextPortNumAvailable: PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-145 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 220: Dspimainfo
NotInGroup Unusable Unusable NotInGroup NotInGroup Unusable Unusable NotInGroup NotInGroup Unusable Unusable NotInGroup NotInGroup PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-146 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 221: Dspimaln
: No Failure LinkRelDelay LinkRxTestPattern Ne Link Tx Num Failures Ne Link Rx Num Failures PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-147 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 222: Dspimalncnt
Ima FeRx Num. Failures # HEC errored cells # HEC errored seconds # Severely HEC errored seconds Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-148 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 223 IMA group number -- value ranging from 1 to 8 line number -- value ranging from 1 to 8 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-149 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 224: Dspimatst
Group No Test Link : 4294967295 Test Status : Disabled Test Pattern : 4294967295 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-150 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 225: Dsplcn
Display the channel number for the connection using port 1 and VPI/VCI 100/100. PXM1E_SF.1.13.AUSMB8.a > dsplcn 1.100.100 LCN number is : 16 PXM1E_SF.1.13.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-151 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 226: Dspln
LocalTiming LineLoopbackCommand: LocalLineLoop LineSendCode: NoCode LineUsedTimeslotsBitMap: 0xffffff LineLoopbackCodeDetection: codeDetectDisabled LineBERTEnable: Disable LineNumOfValidEntries: 8 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-152 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 227: Dsplns
Dis/dsx1B8ZS 0-131 ft LocalTim 21.8 RJ-48 dsx1ESF Mod/dsx1B8ZS 0-131 ft LocalTim LineNumOfValidEntries: 8 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-153 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 228: Dsploads
CBR (based on PCR0+1) VBR (based on PCR0+1) ABR (based on MCR) UBR (based on PCR0+1) Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-154 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 229 Normal Normal Note: All Cell Rates are multiplied by respective Percentage Utilization factors PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-155 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 230: Dspmaptbl
Display map table for the current AUSM. PXM1E_SJ.1.13.AUSMB8.a > dspmaptbl PortNum VCI ChanNum Channel Type ------- --- ------- ------------ PXM1E_SJ.1.13.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-156 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 231: Dspmsgcnt
26626 RiscRcvCtrlMsg: 26625 SARXmtCtrlMsg: 26625 SARRcvCtrlMsg: 26625 SARCtrlMsgDiscLenErr: SARCtrlMsgDiscCRCErr: SARCtrlMsgDiscUnknownChan: 0 SARCtrlMsgLastUnknownChan: 0 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-157 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 232: Dspplpp
PhysicalPortNumber: CellFraming: CellScramble: No Scramble Plpp Loopback: No Loopback Single-bit error correction: Enabled PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-158 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 233: Dspport
PhysicalPortNumber: CellFraming: CellScramble: No Scramble Plpp Loopback: No Loopback Single-bit error correction: Disabled PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-159 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 234 IMAGrp Failure status : No Failure Timing reference link ImaGroupTxImaId : 0x0 ExpectedGroupRxImaId : 0x1 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-160 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 235: Dspportcnt
Related Commands dspport, dspports Attributes Log: No State: Any Privilege: Any User Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-161 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 236 HECErroredSeconds: SeverelyHECErroredSeconds: Syntax : dspportcnt "port_num" port number -- values ranging from 1-8 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-162 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 237: Dspportq
PortBinState: Enabled ServiceSequence: QueueDepth(cells): CLPThresholdHigh(cells): CLPThresholdLow(cells): EFCIThreshold(cells): QueueAlgorithm: MaxBandwidthIncrement: MinBandwidthIncrement: QCLPState: QFullDiscardedCells: CLPSetDiscardedCells: PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-163 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 238: Dspportqs
Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled Enabled PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-164 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 239: Dspportrscprtn
------------ ------ ----- ------- PNNI 1000 / 255 1 / 1000 / 65535 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-165 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 240: Dspports
1.2.3.4 Active NextPortNumAvailable: ImaGrp Sync State ------ ---------- Far-End Permanent Syntax : dspports PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-166 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 241: Dsprscprtn
------------ ------ ----- ------- PNNI 1000 / 255 1 / 1000 / 65535 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-167 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 242: Dspsarcnt
Total CellsCLP: Total CellsAIS: Total CellsFERF: Total CellsEnd2EndLpBk: 0 Total CellsSegmentLpBk: 0 RcvCellsDiscOAM: PXM1E_SJ.1.13.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-168 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 243: Dspsarcnts
Total CellsFERF: Total CellsEnd2EndLpBk: 0 Total CellsSegmentLpBk: 0 RcvCellsDiscOAM: Type <CR> to continue, Q<CR> to stop: Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-169 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 244: Dspslftst
PXM1E_SJ.1.21.AUSMB8.a > dspslftst SelfTestEnable: Disable SelfTestPeriod: SelfTestState: SelfTest Passed SelfTestResultDescription: No failure information available PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-170 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 245: Dspslftsttbl
Line loopback test CellBus test DPRAM test CSERAM test CAM test IMA grp lpbk test PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-171 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 246: Dspstatparms
Current File Size: Stat Memory Allocated: Auto Memory Allocated: Auto Mem Rgn Size: 1843200 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-172 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 247: Dsptaskinfo
1413 2270 logd 2643 qRpc alarm_task 0 2051 ilmi 1036 itut bertd PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-173 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 248: Dsptotals
--------------------------------------- Port Number Port State Number of active Channels DOWN DOWN DOWN DOWN PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-174 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 249: Help
Group 1 clralm Group 5 clralmcnt Group 5 Type <CR> to continue, Q<CR> to stop: Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-175 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 250 800f00b0 80d1d110 ConnectionLo 80d1aff0 55 PEND+T 801172a0 80d1aed0 3d0004 itut imaTableUpda 80d16c00 55 PEND 801172a0 80d16a88 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-176 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 251 80d0a5b0 100 PEND 801172a0 80d0a478 resyncSmrc smrcStartFin 80d083c8 100 PEND 800fc2e0 80d08300 3d0002 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-177 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 252: Memshow
------ --------- -------- ---------- ---------- current free 7731976 12551 7509496 alloc 3297984 8272 cumulative alloc 19442880 331033 PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-178 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 253: Myid
Example Display the user name used for log in. PXM1E_SJ.1.21.AUSMB8.a > myid superuser PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-179 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 254: Oldcnfcdrscprtn
1 to 1000. Related Commands cnfcdrscprtn, delcdrscprtn, dspcdrscprtn Attributes Log: Yes State: Active Privilege: Group 1 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-180 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 255: Restartimagrp
Relearn IMA group ID = 3 • Related Commands cnfautorestart, dspautorestart Attributes Log: No State: Active Privilege: Group 1 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-181 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 256 Restart IMA group 1 using the previously learned IMA group ID for the far end. PXM1E_SJ.1.1.AUSMB8.a > restartimagrp 1 2 PXM1E_SJ.1.1.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-182 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 257: Rrtcon
Privilege: Group 1 Example Reroute the connection using LCN 19. PXM1E_SJ.1.4.AUSMB8.a > rrtcon 19 PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-183 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 258: Runslftstno
Run self test number 9. PXM1E_SJ.1.21.AUSMB8.a > runslftstno 9 Test Number 9 Result: PASS PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-184 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 259: Setcmdc
Privilege: Any User Example Enable the command completion feature. PXM1E_SJ.1.21.AUSMB8.a > setcmdc on PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-185 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 260: Setpagemode
State: Any Privilege: Any User Example Enable command report paging. PXM1E_SJ.1.21.AUSMB8.a > setpagemode on PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-186 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 261: Tstcon
Test connection 100/100 on port 1. PXM1E_SJ.1.4.AUSMB8.a > tstcon 1.100.100 PXM1E_SJ.1.4.AUSMB8.a > TestCon in progress. TestCon Passed. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-187 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 262: Tstconseg
Test the connection labeled channel 16. PXM1E_SJ.1.13.AUSMB8.a > tstconseg 16 PXM1E_SJ.1.13.AUSMB8.a > Segment Loopback Test (CPE side) Failed. Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-188 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 263: Tstdelay
PXM1E_SJ.1.4.AUSMB8.a > tstdelay 16 PXM1E_SJ.1.4.AUSMB8.a > TestDelay in progress. TestDelay Passed with 1 ms. PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-189 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 264: Upcon
Bring up the connection on port 2, VPI/VCI 100/100. PXM1E_SJ.1.4.AUSMB8.a > upcon 2.100.100 PXM1E_SJ.1.4.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-190 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 265: Version
Kernel: WIND version 2.4. Made on Mon Jul 1 23:25:34 PDT 2002. Boot line: PXM1E_SJ.1.21.AUSMB8.a > Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-191 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 266 Chapter 4 AUSM Command Reference version Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 4-192 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 267 4-30, 4-31 AUSM-8E1 clralm 4-32 back cards supported clralmcnt 4-33 maximum connections clralmcnts 4-34 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 IN-1 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 268 4-81 conventions xxiv cnfupccbr 4-83, 4-85 objectives xiii cnfupcubr 4-85, 4-87 organization xiii Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 IN-2 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 269 2-8, 3-4, 4-153 dsploads 4-154 dspmaptbl 4-156 dspmsgcnt 4-157 dspplpp 4-158 dspport 2-12, 3-7, 4-159 dspportcnt 4-161 Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 IN-3 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 270 CLI commands See PVC management procedures setcmdc 4-185 setpagemode 4-186 SMB-8E1 back card Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 IN-4 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 271 3-16, 4-187 tstconseg 4-188 tstdelay 3-17, 4-189 upcon 4-190 version 3-4, 4-191 warning definition Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 IN-5 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...
Page 272 Index Cisco AUSM Software Configuration Guide and Command Reference for MGX 8850 (PXM1E) and MGX 8830 IN-6 Release 3, Part Number 78-14254-01 Rev. A0, October 2002...

This manual is also suitable for:

Mgx 8830

Cisco MGX 8850 PXM1E Software Configuration Manual And Command Reference

Table 2 WAN Ciscoview Release 3 Documentation

Table 1 Cisco WAN Manager Release 11 Documentation

Table 4 Cisco MGX 8850 (PXM1E) Multiservice Switch Release 3 Documentation

Table 5 Cisco MGX 8950 Multiservice Switch Release 3 Documentation

Table 6 SES PNNI Controller Release 3 Documentation

Table 9 Cisco MGX 8850 (PXM1) Edge Concentrator Switch Release 1 Documentation

Table 8 Cisco WAN Switching Software Release 9.3 Documentation

Table 10 Cisco MGX 8250 Edge Concentrator Switch Release 1 Documentation

Table 11 Cisco MGX 8230 Edge Concentrator Switch Release 1 Documentation

Chapter 2 Provisioning Communications Links

Chapter 3 AUSM Card Management

Chapter 4 AUSM Command Reference

Addcon

Addln

Clear

Clralm

Cls

Cnfcon

Cnfln

Delcon

Delln

Delport

Dncon

Dspalm

Dspalms

Dspcd

Dspchan

Dspchans

Dspcon

Dspcons

Dspilmi

Dspimaln

Dsplcn

Dspln

Dsplns

Dsploads

Dspplpp

Dspport

Dspportq

Dspports

Help

Memshow

Myid

Rrtcon

Setcmdc

Tstcon

Tstdelay

Upcon

Version

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cisco MGX 8850 PXM1E

Summary of Contents for Cisco MGX 8850 PXM1E
