Expansion Stages and System Capacity
3. 2

Basic system

Mitel 415and Mitel 430 are based on the same basic system, they differ in terms of the
components fitted to the mainboard, the expansion possibilities and the system capac-
ities. The basic systems consists of the following components:
• Mainboard with front panel, screw covers and designation label integrated in metal
housing with detachable plastic cover
• Power supply unit with power cord
3. 2. 1

Interfaces, display and control elements

The following mainboard interfaces can be accessed only when the housing cover of
the communication server is open:
Tab. 13 Mainboard
Interfaces
Slots for interface cards
Slots for system modules, type 1
Slots for system modules, type 2
Slots for wiring adapters
Slot for EIM card
2)
Fan interface
1) Not used at the moment
2) The fan is required only if the Mitel 430 is rack-mounted
The following interfaces, display and control elements of the mainboard are routed to
the front panel:
Tab. 14 Front panel
Interfaces
DSI terminal interfaces
FXS terminal interfaces
Ethernet interfaces 10/100BaseT, half/full-duplex
RJ45 sockets on front panel, total
Audio input
Supply input
Pilot key
LED display
The diagram below shows the position of all the interfaces and slots on the mainboard
display and control elements and on the front panel.
40
Mitel 415 Mitel 430 Designation / Remarks
2 4 IC1...IC4 / with snap mechanism
1 1 SM1 / three system modules, stackable
1)
– 1 SM2
2 4 WA1...WAx / one slot per wiring adapter
1 1 EIM / card holder
– 1 FAN / 3-pin connector (Mitel 430 only)
Mitel 415 Mitel 430 Note
16
2 4 RJ45 socket
2 2 RJ45 socket
2 2 RJ45 socket
24 RJ45 socket
1 1 3-pin jack socket
1 1 2-pin supply socket
1 1
1 1
