1)
System phone
Expansion key module MiVoice M535
DECT radio unit without power supply unit SB-4+
DECT radio unit without power supply unit SB-8
DECT radio unit with power supply unit SB-4+/SB-8
2)
Office 10
2)
Office 25
2)
Office 35
2)
Office 45
Office 45pro power supply unit
Expansion key module (EKP)
Expansion key module (EKP)
2)
Alpha keyboard
1) Assumptions:
System phones: In hands-free mode, loudspeaker on maximum volume, all LEDs lit
MiVoice 5380: Backlighting with maximum brightness
Expansion key modules: All LEDs lit
Radio units: Active call connection on all channels
2) Although no longer available, the phone is still supported.
3) The value can increase to approx. 600 mW if the power available at the DSI-AD2 bus allows it.
4) An MiVoice M535 always requires a power supply unit
5) The value applies to radio units with hardware version "-2". The value for hardware version "-1" is 300 mW
lower.
6) The value applies to each interface and to radio units with hardware version "-2". The value per interface for
radio units with hardware version "-1" is 150 mW lower.
7) The value applies to phones with hardware version "-2". The value for phones with hardware version "-1" is
60 mW lower.
The two diagrams below show the power available on the DSI-AD2 bus in relation to
the line length and the wire diameter. The table can then be used to determine the
number and type of system phones that can be connected to the DSI-AD2 bus under
the given conditions. The power available can be calculated by measuring the loop re-
sistance where the wire diameter is known.
Due to the different hardware versions of the radio units, basic systems and interface
cards, the power available on the DSI-AD2 bus is not the same in every case:
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
2)
2)
2)
Socket
MiVoice 5370, MiVoice 5380
DSI-AD2 interface
2 DSI-AD2 interfaces
1 or 2 DSI-AD2 interfaces
DSI-AD2 interface
DSI-AD2 interface
DSI-AD2 interface
DSI-AD2 interface
DSI-AD2 interface
Office 35
Office 45
Office 35, Office 45
Installation
Max. power input
[mW]
4)
0
5)
1700
6)
1550
< 100
900
900
7)
630
7)
1110
< 10
150
210
30
