Equipping the Basic System
For an individual expansion the Mitel 415/430 basic system can be equipped with inter-
face cards, the appropriate wiring adapters and system modules. An overview can be
found in the Chapter "Expansion Stages and System Capacity", page 39.
4. 5. 1
Interface card
Interface cards are fitted to slots IC1...IC4. IC3 and IC4 can be found only on the
Mitel 430 (see Fig. 7).
Warning
Be sure to observe the "Safety regulations", page 84.
1. Shut down the communication server (see "Shutdown Mode", page 206) and dis-
connect it from the power supply.
2. Remove the housing cover.
3. Place the interface card at a slight angle into the required slot (see Fig. 23). Make
sure the angled side of the interface card is facing backwards (i.e. it must not project
over the wiring adapter slots).
4. Carefully press the interface card downwards until the two lateral metal clamps en-
gage.
5. Fit the corresponding wiring adapter (see "Wiring Adapter", page 98) into the appro-
priate wiring adapter slot WA1...WA4.
6. Fit the housing cover.
7. Reconnect the communication server to the power supply.
