Boot Mode; Shutdown Mode - Mitel 430 System Manual

Operation and Maintenance
Tab. 98 Warning Mode combination patterns
F0 F1 F2
– – –
– – –
6. 4. 3. 8

Boot Mode

The boot mode enables an Emergency Upload via the Ethernet interface. This is re-
quired whenever there is no longer any executable system software stored on the com-
munication server for whatever reason or if a downgrade to an older software version
is to be carried out.
The Boot Mode is indicated by the SYS-LED flashing red.
To access the boot mode press the control key during the LED test red, which is exe-
cuted during the start-up phase (see pattern[1], Tab. 92). The length of time the pilot
key is pressed is irrelevant. The red LEDs go off once the control key is pressed. After
a wait time of approx. 30 seconds, Pattern [21] of the boot mode is displayed.
Tab. 99 Combination patterns in Boot Mode
Pattern
F0 F1
No.
[21]
– –
The boot mode remains active until the Emergency Upload is completed or the system
is restarted manually.
6. 4. 3. 9

Shutdown Mode

If, for maintenance purposes, the communication server is disconnected from the
power supply, it must be shut down under control (see "Shutting down the communica-
tion server", page 209). It then remains in Shutdown Mode for three minutes before it
starts again automatically. During this period the communication server can be discon-
nected from power supply.
Notes:
Never disconnect the communication server from the power supply to trigger a restart. This can
result in data losses and prevent a restart.
Combination pattern [22] is displayed in shutdown mode.
