Mitel 430 System Manual page 139

Port 4
Port 3
Port 2
Port 1
Fig. 63 Jumper configuration for connecting a door intercom
Note
If the options card is fitted on slot IC2 (Mitel 415 or slot IC4 (Mitel 430), the jumpers of Ports 1, 2
and 3 must be fitted as shown in Fig. 63.
Connection
Tab. 65 Connection in Slot 2 (Mitel 415) or Slot 4 (Mitel 430)
RJ45
Socket X1
Socket X2
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
free control input (marked ) or control
IO4
output (signified)
TO
TS Configured for connecting a door intercom
KT
Communica-
tion server
Pin Signal
1 –
2 –
3 KT1
4 TS2
5 TS1
6 KT2
7 –
8 –
Pin Signal
1 –
2 –
3 TO2
4 IO4
5 IO4
6 TO1
7 –
8 –
RJ45
Socket X3 Pin
1
2
3
4
5
6
7
8
Socket X4 Pin
1
2
3
4
5
6
7
8
Installation
Communication
server
Signal
–
–
Tb (without DC)
Ta' (with DC)
Tb' (with DC)
Ta (without DC)
–
–
Signal
–
–
–
–
–
–
–
–
139
