Mitel 430 System Manual page 142

Installation
Tab. 68 Connection in slot IC1 (Mitel 415) or slot IC1, 2 or 3 (Mitel 430)
RJ45
Socket X1
Socket X2
Tab. 69 Connections of control inputs and outputs
IO port Signal
1 O1-1, O1-2
2 O2-1, O2-2
3 I3-1, I3-2
4 I4-1, I4-2
Freely connectable relay contacts
The two freely connectable relay contacts can be used to control external devices or
equipment such as heating, alarm or outdoor lighting systems (possibly via external re-
lay for 115/230 VAC).
There are no special requirements for the cables.
Tab. 70 Relay operating data
Parameter
Number of changeover switches per relay
Insulation between the changeover switches
Type of contact
max. contact loading
142
Communication
server
Pin Signal
1 –
2 –
3 O1-1
4 O2-1
5 O2-2
6 O1-2
7 –
8 –
Pin Signal
1 –
2 –
3 I3-1
4 I4-1
5 I4-2
6 I3-2
7 –
8 –
Function
Floating contact, relay 1
Floating contact, relay 2
Control input 1
Control input 2
Value
1
0.5 kV
no (normally open, NO contact, make contact)
24 VDC, 30 VAC, 1 A
RJ45
Socket X3 Pin
1
2
3
4
5
6
7
8
Socket X4 Pin
1
2
3
4
5
6
7
8
