Operation and Maintenance
Parameter 1 (XXYY)
Value Reason (XX)
13 No e-mail recipient address
14 Invalid e-mail recipient address
15 Invalid e-mail sender address
1) Action carried out by the SMTP client at the point when the error occurred.
6. 5. 1. 2

Event tables

Event tables ( =f4) list all the event messages the system is capable of generating
(see Tab. ).
There are 7 event tables. After a first start, all event tables are assigned at least one
destination. This assignment can be modified in the
view. Each event table can be configured individually. This means it is possible with a
filter to decide which event message – if any – should be sent to a particular signal
destination either immediately, with a delay or not at all.
• No event:
This type of incoming event messages are never sent to the linked destination.
• Every event:
This type of incoming event messages are all sent to the linked destination.
• Custom:
With this setting, you can determine how often the event message may appear for
each period, until they are sent to the linked destination.
The Frequency
indicated in hours, ranging between 1 and 672. The longest time period corre-
sponds to 28 days or 4 weeks.
Tab. 105 Example of event table
Event type
Total synchronization loss
In this example an event message is sent to the message destinations if there is a
tal synchronization loss
sage 10 times within 1 hour.
230
of an event message may range between 2 and 20. The
Frequency
10
event message when the system generates the event mes-
1)
Action (YY)
Prepare encrypted
authentication (CRAM-
MD5)
Encrypted authentica-
tion (CRAM-MD5)
Preparing to send next
e-mail
Message destinations
Time period
1
Parameter 2: Parameter 3:
Additional info
E-mail client depending on the
e-mail client (XXYY)
((
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
=h1))
Period is
To-
