Terminal cards

Terminal cards are used for connecting digital and analogue voice and data terminals
such as:
FXS cards are an exception. Their analogue interfaces are multifunctional. In addition
they provide interfaces for controlling external devices and switching over internal
switch groups. Depending on the terminal or function, the interfaces are configured in-
dividually and switched over internally accordingly (see "Multifunctional FXS inter-
faces", page 127).
DSI cards are used for connecting digital system terminals such as phones. 2 terminals
can be connected to each DSI interface.
Terminals to ETSI standard are connected via BRI cards. The cards contain both termi-
nal interfaces (BRI-S) and network interfaces (BRI-T). On these cards the ratio of BRI-
S interfaces to BRI-T interfaces is determined by the type and plug-in orientation of the
Wiring Adapters (see "Wiring Adapter", page 98).
Tab. 25 Terminal cards
Terminal inter-
Type
faces per card
4 × DSI
EADP4
1)
4 × DSI
EAD4V
1)
4 × DSI
EAD4C
4 × FXS
ETAB4
3 × BRI-S/T
TIC-4TS
1 × BRI-T
2 × BRI-S/T
TIC-2TS
1)2)
1 × BRI-S/T
ESST
1 × BRI-S
1) Although no longer available, the card is still supported.
2) Cards with hardware version "-2" only. The ESST-1 card is not operational in Mitel 415/430.
Note
On the ESST terminal card the jumper must always be fitted in position T (see Fig. 24).
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
Expansion Stages and System Capacity
Max. number of Max. number of
Mitel 415 cards Mitel 430 cards
2
2
2
2
2
2
2
Remarks
4
4 • Voice mail functionality of the card can-
not be used
• Cannot be fitted to slot IC4 on Mitel 430
4 • Announcement service functionality of
the card cannot be used
• Cannot be fitted to slot IC4 on Mitel 430
4 • Interfaces individually configurable
4 • Three BRI-S interfaces configurable to
BRI-T
• One fixed BRI-T interface
4 • Both interfaces configurable to BRI-T
4 • One BRI-S interface configurable to
BRI-T, one fixed BRI-S interface
• The jumper on this card must always be
fitted to position T.
