Installation
Power supply
The EFOP fan-out-panel needs its own power supply and is powered by the supplied
power supply unit FSP065 via one of the two equivalent supply sockets. The power
supply unit is connected to the mains using a two-pin standard power cable.
Input values EFOP fan-out-panel 19 VDC / 0.5 A
Hazard:
Hazard due to heat generation in the event of short-circuits. The mains power supply connec-
tion must be protected with 16 A maximum in countries with 230 V mains power (for instance in
Europe), and with 20 A maximum in countries with 115 V mains power (e.g. in North America).
Please also note the following points:
• The mains connector acts as a disconnecting device and must be positioned so that
it is easily accessible.
• Original power supply units FSP065 (19 VDC / 3.42 A) are to be used exclusively.
• The EFOP fan-out-panel is designed for installation in a 19" rack and must be fitted
in rack only.
Earthing
The EFOP fan-out-panel has 4 equivalent connections for the protective earthing (see
Fig. 61).
Warning
Because analogue trunk lines are to be routed via the fan-out panel EFOP, for safety reasons
the fan-out panel must be connected to the protective earth.
