Remove a PCIe Card

6. Pull the PCIe card carrier handle down to disengage the carrier from the card
cage.
Remove the PCIe card carrier from the server.
7.
Related Information
"Understanding PCIe Root Complex Connections" on page 165
■
"PCIe Card Configuration" on page 168
■
"PCIe Carrier Handle and LEDs" on page 169
■
"Determine Which PCIe Card Is Faulty" on page 170
■
"Remove a PCIe Card" on page 174
■
"Install a PCIe Card" on page 177
■
"Install a PCIe Card Carrier" on page 180
■
"Verify a PCIe Card" on page 181
■
Remove a PCIe Card
Caution -
discharge. This discharge can cause failure of server components.
1. Ensure that you have already taken antistatic measures.
See "Prevent ESD Damage" on page
174 SPARC T7-4 Server Service Manual • May 2017
This procedure requires that you handle components that are sensitive to electrostatic
49.
