Install a PCIe Card
3. Insert the PCIe card into the PCIe card carrier until the bottom connector is
firmly seated in the PCIe card carrier's connector.
Caution -
that the PCIe card's connector is fully seated in the PCIe card carrier's slot, and that the notch in
the PCIe card's rear bulkhead is seated around the PCIe carrier's alignment tab.
178 SPARC T7-4 Server Service Manual • May 2017
Do not twist or turn the PCIe card as you insert it into the PCIe card carrier. Ensure
